02 Low pressure equipment

Bayonet quick couplings
Couplings with tail Couplings with male and female thread

Straight. Brass Swivel straight. Suction coupling *. M thread. Brass F thread. Flat seal.
Brass Brass Brass
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
10 mm (3/8") 720 05 45 1/4" 723 05 23
13 mm (1/2") 720 10 45 720 104 60 724 30 79 3/8" 723 10 24 722 10 23
16 mm (5/8") 720 15 45 1/2" 723 20 24 722 20 23
19 mm (3/4") 720 20 45 720 204 55 724 15 74 3/4" 723 30 22 722 30 23
25 mm (1") 720 30 51 720 304 67 724 25 78 1" 723 40 23 722 40 23
32 mm (1.1/4") 720 40 62 720 404 75 1.1/4" 723 50 26 723 00 28
38 mm (1.1/2") 720 50 68 1.1/2" 723 60 35 723 01 30
* Leak proof. Twist on sleeve locks in place
Spare washer Accessories

Flat seal. For F thread Gasket 100 meshes/cm. Bayonet blank 3-way distributor 3-way bayonet
R+M Nr. Brass. Strainer coupling with 3/4" F : 3/4" M : coupling.
insert. 33 mm gasket. Brass 3/4" M. Brass Brass
725 23 3/8"
725 24 1/2" R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
725 25 3/4" 725 20 725 30 725 10 725 05 725 00
725 26 1"
725 27 1.1/4"
725 28 1.1/2"
Low pressure quick coupling ST-45

new

ST-45. ST-45. ST-45. ST-45.
Nickel-plated brass. Nickel-plated brass. Nickel-plated brass. Nickel-plated brass.
Quick Coupling : Quick Coupling : Plug nipple with Plug nipple with
3/4" F. 1" F. hose barb hose barb
25 bar / 90° C 25 bar / 90° C 13-19 mm. 19-25 mm.
25 bar / 90° C 25 bar / 90° C
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
200 045 210 200 045 230 010 000 455 010 000 456

KTW approved bayonet quick couplings are available on request!

Symbols thread height nominal diameter diameter
