Page 15 - RM_2022

02 Low pressure equipment

Spray guns
Shower head Gun with seven jet adjustments Gun with infinitely variable jet adjustment

Stainless steel. Housing plastic. Inlet 1/2" F. Plug 16 mm (universal) and 3/4" F. Plug 16 mm (universal) and 3/4" F.
Max. 8 bar / 60 °C Max. 8 bar / 20 °C Max. 8 bar / 20 °C
R+M Nr. R+M Nr. R+M Nr.
500 101 726 419 726 416
Spray nozzles

Spray nozzles Ball valves

Adjustable with bayonet coupling Adjustable with hose tail. Brass 3/4" F : 3/4" M. Brass. Max. 8 bar / 50 °C
R+M Nr. R+M Nr. R+M Nr.
726 81 726 811 13 mm (1/2") 726 420

Micro Droplets Nozzle Holder
Fields of application: Nozzles for Micro Droplets Nozzle Holder
functioning
Disinfection, humidification, cooling, dust
suppression, decontamination, odor control in ag- of Micro Droplets Nozzle Holder
ricultural, food and construction industry, defence
and firefighting technology, car washing and de-
tailing

M15x1 M. Stainless steel
R+M Nr.
200 078 412 1.2 mm
200 078 415 1.5 mm
200 078 418 1.8 mm
200 078 420 2.0 mm
200 078 423 2.3 mm
ST-78. Stainless steel 200 078 425 2.5 mm
R+M Nr. progressive, conical spray jet 200 078 430 3.0 mm
200 078 830 1/4" F 200 078 435 3.5 mm

Symbols nozzle diameter inlet outlet nominal diameter

14
