02 Low pressure equipment

Low pressure hoses
Rubber hoses black Rubber hoses grey Plastic hoses yellow

QUATTROFLEX PLUS + Yellow cover with light
Black surface and interior. Industrial version Grey NBR surface. White, food safe interior. blue inner tube. 24-thread diagonal reinforce-
for water and compressed air. Abrasion- and Suitable for hot and cold liquids. Resistant to ment: extremely pressure-resistant and dimen-
ozone-resistant. Burst pressure > 60 bar. animal fats. Burst pressure > 60 bar. sionally stable. No twisting, no kinking. Highest
Max. 20 bar. -10 °C - +60 °C Max. 20 bar. -20 °C - +100 °C flexibility and temperature resistance. Abrasion
Per metre Per metre and UV resistant. Lead and cadmium free
Phthalate free, food safe. Burst pressure > 35 bar.
R+M Nr. R+M Nr. -20 °C - +60 °C
305 10 13 (1/2") 4 305 40 13 (1/2") 4.5
Complete rolls
305 20 19 (3/4") 5 305 50 19 (3/4") 4.8
305 30 25 (1") 5 R+M Nr.
Spiral line hoses
305 012 25 13 (1/2") 25 m 2.5
Complete rolls *
305 012 50 13 (1/2") 50 m 2.5
R+M Nr. 305 034 25 19 (3/4") 25 m 3.1
305 101 00 13 (1/2") 100 m 4 305 034 50 19 (3/4") 50 m 3.1
305 201 00 19 (3/4") 100 m 5
Clear PVC hoses
305 301 00 25 (1") 100 m 5
Reinforced PVC hoses clear
Especially for suction. Suitable for vacuum.
-10 °C - +50 °C
Per metre
R+M Nr. Especially for suction of chemicals. Max. 60 °C.
307 519 19 (3/4") 2.6 Other dimensions are available on request
307 525 25 (1") 2.7 Per metre
307 532 32 (1.1/4") 2.7
Clear. Max. 60 °C. 307 538 38 (1.1/2") 2.7 R+M Nr.
Other dimensions are available on request 307 550 50 (2") 4.0 306 10 4 1.0
306 20 6 1.5
Per metre
Complete rolls 306 30 8 2.0
R+M Nr.
R+M Nr. Complete rolls
306 40 6 3.0
307 519 025 19 (3/4") 25 m 2.6
306 50 8 3.0 R+M Nr.
307 525 025 25 (1") 25 m 2.7
306 55 9 3.0 306 101 00 4 100 m 1.0
307 532 025 32 (1.1/4") 25 m 2.7
306 60 10 3.0 306 201 00 6 100 m 1.5
307 538 025 38 (1.1/2") 25 m 2.7
307 10 12 3.0 306 301 00 8 100 m 2.0
307 550 025 50 (2") 25 m 4.0
306 70 13 3.0
306 80 16 3.0 Reinforced PVC hoses blue Reinforced PVC hoses yellow
306 90 19 3.5
Complete rolls
R+M Nr.
306 401 00 6 100 m 3.0
306 501 00 8 100 m 3.0 Max. 60 °C. Other dimensions are available on request Max. 60 °C. Other dimensions are available on request
306 550 50 9 50 m 3.0
Per metre Per metre
306 600 50 10 50 m 3.0
307 100 50 12 50 m 3.0 R+M Nr. R+M Nr.
306 700 50 13 50 m 3.0 080 000 310 9 3 080 000 300 6 3
306 800 50 16 50 m 3.0 306 71 13 3 080 000 320 9 3
306 900 50 19 50 m 3.5
Complete rolls Complete rolls
R+M Nr. R+M Nr.
306 560 50 9 50 m 3 306 410 50 6 50 m 3
306 710 50 13 50 m 3 306 570 50 9 50 m 3
Symbols nominal diameter mm wall thickness mm length pressure burst pressure weight
