Low pressure equipment 02

Hose clamps
1.4016 stainless steel housing and band. Heavy duty clamp
Hexagon screw zinc-plated. Worm gear high tension.
Heavy duty clamp completely stain-
Flat tape inner sides with turned up rims.
less steel X5CrNi1810. According to
According to DIN 3017, W2
DIN 1.4301/AISI 304
W4 and W5 completely
rust-free, is available
on request
Clamps with hexagon screw. 9 mm
R+M Nr. R+M Nr.
735 10 1 8 - 12 mm 735 101 00 100 8 - 12 mm
735 20 1 10 - 16 mm 735 201 00 100 10 - 16 mm
735 30 1 12 - 20 mm 735 301 00 100 12 - 20 mm
735 40 1 16 - 25 mm 735 401 00 100 16 - 25 mm
735 50 1 20 - 32 mm 735 501 00 100 20 - 32 mm
735 60 1 25 - 40 mm 735 601 00 100 25 - 40 mm Clamp with hexagon bolt. W4. 20 mm
735 70 1 32 - 50 mm 735 701 00 100 32 - 50 mm R+M Nr. R+M Nr.
735 80 1 50 - 70 mm 735 801 00 100 50 - 70 mm 736 029 401 1 29 - 31 mm 736 032 401 1 32 - 35 mm
Wall brackets

Hose holders

125
Ø 9

Ø 8 200
160

360
Holding capacity 1/2" = 40 m - 3/4" = 30 m. Holding capacity 1/2" = 40 m - 3/4" = 30 m. Holding capacity 1/2" = 40 m - 3/4" = 30 m.
Hole spacing 140 mm. Hole spacing 140 mm. Hole spacing 125 mm.
W x H x D = 260 x 165 x 170 mm W x H x D = 280 x 140 x 130 mm W x H x D = 360 x 200 x 170 mm
R+M Nr. R+M Nr. R+M Nr.
110 00 plastic 110 05 powder-coated steel 110 06 polished stainless steel 1.4301
Hose holder aluminium Brush holder

R+M Nr. holding capacity Suitable for all brushes.
110 01 S 1/4" = 30 m - 3/8" = 20 m 155 77 188 145 70 5.5 Hole spacing 202 mm.
110 02 M 3/8" = 30 m - 1/2" = 20 m 255 107 266 200 108 6.0 W x H x D = 250 x 90 x 100 mm
110 03 L 1/2" = 30 m - 3/4" = 20 m 272 145 348 255 143 8.0 R+M Nr.
110 031 XL 3/4" = 30 m - 1" = 20 m 366 162 417 307 187 10.0 108 290 30 stainless steel
