Low pressure equipment 02

Filter housings without cartridge filter
Plastic Brass / plastic Stainless steel

2-pieces. With drain. 3-pieces. With drain. 3-pieces. With drain. Head nickel- 3-pieces. With drain, key for housing
Female thread brass. Female thread brass. plated brass. Filter cup plastic. and mounting bracket.
Max. 10 bar / 50 °C Max. 10 bar / 40 °C Max. 15 bar / 40 °C Max. 20 bar / 120 °C

R+M Nr. R+M Nr. R+M Nr. R+M Nr.

734 50 ■ 3/4" 5" 188 734 290 03 ■ 3/4" 5" 207 734 330 2 ■ 1" 9.3/4" 315 734 304 1 ■ 1" 9.3/4" 350

734 60 ■ 1" 5" 188 734 290 11 ■ 1" 5" 207

734 81 ■ 1-1/4" 9.3/4" 310 734 290 04 ■ 3/4" 9.3/4" 337

734 70 ■ 3/4" 9.3/4" 310 734 290 05 ■ 1" 9.3/4" 337
734 80 ■ 1" 9.3/4" 310
734 820 034 ■ 3/4" 20" 583
734 820 001 ■ 1" 20" 583
Screen housings O-ring Centering unit

R+M Nr.
734 506 ■■■ For assembly.
734 510 ■ Centering aid
734 200 70 ■■ R+M Nr.
734 304 11 ■ 734 210 36 ■■
Filter 2-pieces. Plastic. Max. 50 °C Filter 3-pieces. Plastic. Max. 40 °C
R+M Nr. R+M Nr.
734 504 ■ small* 734 200 13 ■ small**
734 704 ■ big* 734 200 14 ■ big**
734 330 21 ■ big**
Mounting brackets Keys for housing

For plastic head. For 2 For brass head. For 3
Single. Zinc-plated steel Single. Plastic Double. Plastic pieces filter housing. pieces filter housing.

R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
734 299 02 ■■ 734 507 ■■■ 734 508 ■■■ 734 505 ■■■ 734 300 1 ■
734 299 01 ■■

* with o-ring ** without o-ring
