02 Low pressure equipment

Foam gun
Applications
Designed for applications with acidic and caustic cleaner, soaps,
disinfectants, degreasing and softening agents. The field of application is
very versatile.
» Food industry and canteen kitchen
» Sanitary facilities and swimming baths
» Cleaning of trucks, cars and other vehicles
» Garages and petrol stations
» Shops and workshops
The foam gun directly connected to the public water pipe produces a
cleaning foam by means of foam injector. The water pressure sucks in the
cleaning agent and air, both are being mixed to consistent foam, sprayed
out via the spraying head and the foam wand. The cleaning agent can also
purposely and automatically be diluted via a built-in proportioner so that
the right mixture of chemical and water as foam can be chosen for the
cleaning application.
Technical specifications

Features Water pressure 2.5 - 6 bar (for maximum accuracy 3 - 4 bar)
Output 5.5 l/min
» Exceptional chemical resistance to acidic and caustic cleaner.
Mixing Ratio
» Foam generating wand creates a thick clinging foam.
» Automatic dosing of chemicals. Multi-ratio dial has 5 mixing settings and off
» Durable polymer mixing head with stainless steel screws.
» Multi-ratio dial has 5 mixing settings and off. A B C D E 0
» Gun is removable from quick coupling for clear rinsing with water. 1:128 1:64 1:32 1:20 1:10 off
» Easy filling by means of wide mouth.
» Only works with water pipe pressure.
» Suitable for all customary water couplings. R+M Nr.
» Chemical container volume 1,000 ml 106 996 500 incl. coupler plugs "universal" 1 l

Please use the backflow preventer (R+M Nr. 734 10) on page 26.

Symbols thread volume
