03 High pressure equipment

INTERPUMP high pressure pumps with built-in valve
Version "V" Repair kits
01 02 03 04

Valves 6 pieces Seal kit for 1 piston Sleeve kits for Oil seal kits for
3 pistons 3 pistons
Version "BV" 05 06 07 08

Ceramic socket for Valve plugs. Kit with O-ring for valve plugs
1 piston 6 plugs 1 piece

"V" "BV" 01 02 03 04 05 06 07 08
serie R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
180 13 2.800 4 WW186 44 001 860 03 ■ 001 860 05 ■ 340 123 01 340 130 01 340 088 01 340 023 01 520 400 09 340 124 01 903 847 00
200 15 2.800 5,5 WW209 44 002 090 03 ■ 340 123 01 340 130 01 340 088 01 340 023 01 520 400 09 340 124 01 903 847 00

■ Type "H" is equipped with an automatic pressure regulator that allows to zero the pump pressure.

INTERPUMP special high pressure pumps

Version "VHT" Repair kits
01 02 03 04

Valves 6 pieces Seal kit for 1 piston Sleeve kits for Oil seal kits for
3 pistons 3 pistons
05 06 07 08

Series "VHT". Made out of high quality components and
materials. Especially designed for car wash and industrial Ceramic socket for Tension screws for Valve plugs O-ring for valve plugs
applications of up to 85 °C 1 piston 3 pistons 1 piece
"VHT" 01 02 03 04 05 06 07 08
Serie R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
140 21 1,450 5.5 VHT4721 47.VHT 047 210 01 340 201 01 340 203 01 340 202 01 340 002 01 470 405 09 340 006 01 340 005 01* 903 847 00
160 15 1,450 4.5 VHT4715 47.VHT 047 150 01 340 201 01 340 203 01 340 202 01 340 002 01 470 405 09 340 006 01 340 005 01* 903 847 00
160 18 1,450 5.5 VHT4718 47.VHT 047 180 01 340 201 01 340 203 01 340 202 01 340 002 01 470 405 09 340 006 01 340 005 01* 903 847 00
170 46 1,750 14.7 VHT6646 66.VHT 066 460 01 340 169 01 340 211 01 340 210 01 340 002 01 660 404 09 661 303 41 903 857 00
200 39 1,750 14.7 VHT6639 66.VHT 066 390 01 340 169 01 340 209 01 340 208 01 340 002 01 660 401 09 661 303 41 903 857 00
* Kit with 6 valve plugs

The photos showing the pumps and repair kits are only for your information.
The products might differ from the photos regarding their dimension and design.
