03 High pressure equipment

Annovi Reverberi high pressure pumps
Pump series 228, type "JK" Car Wash Repair kits
01 02 03 04

Carwash pump max. 85 ° C with at least 2 bar pre-pressure. Valves 6 pieces Seal kits for 3 Oil seal kits Ceramic socket for
Ideal for the car wash sector due to its long service life pistons 3 pistons

R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
120 13 1,450 4.0 JK 13.12 N DX 170 278 64 170 286 4 170 422 13 170 434 03 170 434 02 18 40
150 15 1,450 4.0 JK 15.15 N DX 170 278 65 170 286 4 170 422 13 170 434 03 170 434 02 18 40
150 21 1,450 5.5 JK 21.15 N DX 170 278 66 170 286 4 170 425 64 170 434 03 170 461 10 22 40
Annovi Reverberi high pressure pumps for Car Wash

Motor pump combinations Repair kits
01 02 03 04
new

400 V. All models are equipped with a regulation valve*, delayed
total stop control, pressure gauge, 5 m electric cable and an on- Valves 6 pieces Seal kits for 3 Oil seal kits Ceramic socket for
off switch. 1/2" F 3/8" M. pistons 3 pistons
Max. 85 °C at min. 2 bar inlet pressure
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
120 13 1,450 4.0 HJK 13.12 ET 4KW PTFE 170 278 70 170 286 4 170 422 13 170 434 03 170 434 02 18 40
150 15 1,450 4.0 HJK 15.15 ET 4KW PTFE 170 278 71 170 286 4 170 422 13 170 434 03 170 434 02 18 40
150 21 1,450 5.5 HJK 21.15 ET 5,5KW PTFE 170 278 72 170 286 4 170 425 64 170 434 03 170 461 10 22 40

Pump/motor assignment

Pump coupling flange solid shaft
Annovi Reverberi for Car Wash
170 278 64 JK 13.12 N DX 100 151 11 100 015 10 175 002 001 4.0
170 278 65 JK 15.12 N DX 100 151 11 100 015 10 175 002 001 4.0
170 278 66 JK 21.12 N DX 100 151 11 100 015 10 175 002 002 5.5

Symbols inlet outlet

56
