Page 61 - RM_2022

03 High pressure equipment

Suttner regulation valves ST-261
ST-261 for panel mounting ST-261 for panel mounting ST-261 for panel mounting with pressure switch

139 139
210

40 40
40
85 85

= inlet 3/8" F. = outlet 3/8" F. = bypass = inlet 3/8" F. = outlet 3/8" F. = bypass
1/4" F. = pressure gauge 1/4" F. 1/4" F. = pressure gauge 1/4" F. 85
Max. 250 bar / 80 °C Max. 250 bar / 80 °C
R+M Nr. R+M Nr. = inlet 3/8" F. = outlet 3/8" F. = bypass
200 261 559 30 l/min 200 261 557 30 l/min 1/4" F. = pressure gauge 1/4" F. Regulation
valve with pressure switch (IP65) and cable
ST-261 without chemical injector ST-261 with chemical injector 1,200 mm. Max. 250 bar / 80 °C
R+M Nr.
200 261 655 30 l/min
140 140

40 40

85 85

= inlet 3/8" F. = outlet 3/8" F. = bypass = inlet 3/8" F. = outlet 3/8" F. = bypass
1/4" F. = pressure gauge 1/4" F. 1/4" F. = pressure gauge 1/4" F. Hose tail
Max. 250 bar / 80 °C 6 mm. Max. 250 bar / 80 °C
R+M Nr. R+M Nr.
200 261 500 30 l/min 200 261 560 1.8 30 l/min
200 261 570 2.1 30 l/min
200 261 580 2.4 30 l/min
ST-261 with pressure switch three-core ST-261 with pressure switch four core ST-261 with pressure switch limited stock

210 210 190

40 40 40

85
85 85
IP
= inlet 3/8" F. = outlet 3/8" F. = bypass = inlet 3/8" F. = outlet 3/8" F. = bypass = inlet 3/8" F. = outlet 3/8" F.
1/4" F. = pressure gauge 1/4" F. Regulation 1/4" F. = pressure gauge 1/4" F. Regulation = bypass 1/4" F. = pressure gauge 1/4" F.
valve with pressure switch (IP65) three-core and valve with pressure switch (IP65) four-core and Regulation valve with pressure switch (IP55) and
cable 1,200 mm. Max. 250 bar / 80 °C cable 1,200 mm. Max. 250 bar / 80 °C cable 140 mm. Max. 250 bar / 80 °C
R+M Nr. R+M Nr. R+M Nr.
200 261 550 30 l/min 200 261 551 30 l/min 200 261 660 30 l/min

60
