Regulation valves
VB75 VB85 Rep. Kit VB85

Y
X

= inlet 1/2" F. = outlet 3/8" F. Regulation = inlet 1/2" F. = outlet 1/2" F. = bypass
valve with banjo-bolt. X: 19 mm. Y: 62-73 mm. 1/2" F. Max. 90 °C
Suitable for IP50, IP44, IP47, IP60, IP63 / Speck
NP16. Max. 250 bar / 90 °C R+M Nr.
R+M Nr. 532 851 6 max. 160 bar 80 l/min R+M Nr.
532 093 0 30 l/min 532 852 8 max. 280 bar 80 l/min 532 851 62
VB80 VB80/150 VB53/500

= inlet 1/2" F. = outlet 1/2" F. = bypass = inlet 1/2" F. = outlet 1/2" F. = bypass = inlet 1/2" F. = outlet 1/2" F. = bypass
1/2" F. Stainless steel. Max. 90 °C 1/2" F. = pressure gauge 1/4" F. Max. 90 °C 1/2" F. Max. 90 °C

R+M Nr. R+M Nr. R+M Nr.
532 802 84 max. 280 bar 80 l/min 532 801 50 max. 150 bar 80 l/min 532 535 00 max. 500 bar 80 l/min
VB26 VRT100/190

= inlet 1/2" F. = outlet 1/2" F. = bypass = inlet 1/2" F. = outlet 1/2" F.
1/2" F. Stainless steel. = bypass 1/2" F.
Max. 90 °C Max. 90 °C
R+M Nr. R+M Nr.
532 262 80 max. 280 bar 80 l/min 532 056 0 max. 190 bar 100 l/min
Symbols inlet outlet bypass pressure gauge flow pressure
