Page 66 - RM_2022

High pressure equipment 03

Regulation valves
VB350 VB350 VB60/600

= inlet 3/8" M. = outlet 3/8" F. = bypass = inlet 3/8" M. = outlet 3/8" F. = bypass = inlet 1/2" F. = outlet 1/2" F. = bypass
1/2" F. = pressure gauge 1/4" F. Regulation 1/2" F. = pressure gauge 1/4" F. 1/2" F. Max. 600 bar / 90 °C
valve with switch (IP55) and cable 1,200 mm. Max. 350 bar / 90 °C
Max. 350 bar / 90 °C
R+M Nr. R+M Nr. R+M Nr.
532 350 40 l/min 532 340 40 l/min 532 260 0 60 l/min
Gymatic 3/B new new new

8

Y Y
Y X X X

= inlet 3/4" F. = outlet 3/8" M. Regulation = inlet 1/2" M. = outlet 3/8" M. Regulation = inlet 1/2" M. = outlet 3/8" M. Regulation
valve with banjo-bolt. X: 8.5 mm. Y: 68-77 mm. valve with banjo-bolt. X: 4.5 mm. Y: 53-64 mm. valve with banjo-bolt. Chemical injector ( 2.1
Suitable for AR Serie XW. Suitable for AR Serie XM, RR, JK and RK. mm), hose tail 8 mm. X: 4.5 mm. Y: 53-64 mm.
Max. 250 bar / 45 °C (*60 °C) Max. 250 bar / 45 °C (*60 °C) Suitable for AR Serie XM, JK and RK.
R+M Nr. R+M Nr. Max. 250 bar / 45 °C (*60 °C)
170 208 02 35 l/min 170 200 80 35 l/min R+M Nr.
170 204 00 13 / 18 l/min
VB60/600 Zeromatic 93

= inlet 1/2" F. = outlet 1/2" F. = bypass = inlet 1/2" F. = outlet 3/8" M.
1/2" F. Regulation valve with micro switch (IP55) = bypass 1/2" F. = pressure gauge 1/4" F.
and cable 950 mm. Max. 600 bar / 90 °C Max. 250 bar / 60 °C

R+M Nr. R+M Nr.
532 265 0 60 l/min 170 290 7 40 l/min * short-term, only
