INTERPUMP regulation valves
K1 K5 K7

185
175 175

65 74
82

111
100 90

= inlet 3/8" F. = outlet 1/2" M. = inlet 3/8" F. = outlet 1/2" M. = bypass = inlet 3/8" F. = outlet 3/8" M. = bypass
= bypass 1/2" M. 1/2" F - 3/4" M. = pressure gauge 1/4" F. 3/8" F. = pressure gauge 1/4" F.
Max. 250 bar / 60 °C Max. 200 bar / 60 °C Max. 200 bar / 60 °C
R+M Nr. R+M Nr. R+M Nr.
100 000 10 9 - 41 l/min 100 000 51 K5.1 11 - 16 l/min 100 000 70 K7.0 8 - 11 l/min
100 000 52 K5.2 16 - 25 l/min 100 000 71 K7.1 11 - 16 l/min
100 000 53 K5.3 25 - 41 l/min 100 000 72 K7.2 16 - 25 l/min
100 000 73 K7.3 25 - 41 l/min
K9 H253
Info about the
valves K1 . K5 . K7 . K9 . BKX.
By means of the valves the pressure
can be zeroed in the entire system
195
(pump and hose).

84,5

91,5
= inlet 1/2" F. = outlet 1/2" M. = inlet 3/8" F. = outlet 3/8" M.
= bypass 1/2" F. = bypass 3/8" F.
Max. 400 bar / 60 °C Max. 250 bar / 60 °C
R+M Nr. R+M Nr.
100 000 95 50 l/min 100 012 53 stainless steel 8 - 30 l/min
H284 H450 H560

195 262 270

84,5 84,5 84,5

91,5 125 125

= inlet 3/8" F. = outlet 3/8" M. = inlet 1/2" F. = outlet 1/2" M. = inlet 1/2" F. = outlet 1/2" F. = bypass
= bypass 3/8" F. = pressure gauge 1/4" F. = bypass 1/2" F. 1/2" F. = pressure gauge 1/4" F.
Max. 280 bar / 85 °C Max. 400 bar / 85 °C Max. 500 bar / 60 °C
R+M Nr. R+M Nr. R+M Nr.
100 002 84 8 - 41 l/min 100 014 40 50 l/min 100 005 60 stainless steel 60 l/min
