High pressure equipment 03

INTERPUMP regulation valves
HM BKX TIMAX

170 275

71
86 60

96 110 130

= inlet 3/8" F. = outlet 3/8" M. = bypass = inlet 1/2" F. = outlet 1/2" F. = inlet 3/4" F. = outlet 1/2" F.
3/8" F. = pressure gauge 1/4" F. = bypass 3/4" F. = bypass 1" F.
Max. 200 bar / 85 °C Max. 600 bar / 60 °C Max. 60 bar / 60 °C
R+M Nr. R+M Nr. R+M Nr.
010 002 00 5 - 41 l/min 010 000 02 60 l/min 010 010 01 200 l/min
Repair kits Rep. Kit BKX
Valve "easystart"

new

R+M Nr. Kit Nr. R+M Nr.
340 058 01 58 K5 010 000 03 Valve delays pressure increase at pump start.
340 060 01 60 K5 Brass / stainless steel.
340 070 01 70 K7 Closes at 4 l/min.
340 072 01 72 HM Max. 350 bar / 150 °C
340 093 01 93 W2, W2L R+M Nr.
340 094 01 94 W2, W2L 200 232 510 3/8" M 1/4" M

Throttle control
IP adjustableIP adjustable RG1
Throttle control for engine motors. It slows RPM down when by-pass is
activated.
70 M5 14
11 14
 3
55 M5 99
37

G 1/4
G 3/8
Regulator with string 1,000 mm. Min. 50 bar. 1/4" M. 15 - 250 bar - 218 - 3,650 psi.
Max. 200 bar / 75 °C Max. 160 °C.
R+M Nr. R+M Nr. Stroke
995 000 00 3/8" M 532 013 0 14 mm 158 g

Symbols inlet outlet bypass pressure gauge flow type weight thread
