Product Specific Accessories
Accessories for Drills, Grinders, Saws and more
Steel Drill Chucks Spindle Adapters
Chuck Compatible Chuck Key R1H-J253 Fit directly on the spindle 30384-5 30712
part no. tool capacity part no. R0H-99 of any standard drill.
7804-255
(mm)
3/8"-24 Female Thread ÍMounting Spindle
drive
R0H-99 Industrial 0-6 R1H-J253 Part no. thread /
6A-99 & production 0 - 10 R0J-J253 male
R0K-99 2 - 13 R1T-J253 30629
drills 1-6 30384-5 3/8"-24 1/2"-20 Male
1 - 10 — 30384-9 3/8"-24 3/8" Square
7804-255 Service 1 - 13 R000B2J70-J253 30712 3/8"-24 1/2" Square
7802-99 drills 3/8"-24 1/4" Hex Quick Change
7803-99 R1T-J253
For 1/4" Hexagonal Shaft
123182 Screwdriver 0-8 Included Tapping Chucks
123205 with 1/4" hex 1 - 10 Included
Used on 7667 Series straight power
Keyless Drill Chucks units or as replacement on 7429-D-EU
(self-reversing) & QP1SxxD8D
Chuck Material Chuck capacity 123182 tappers (JT1 mount),
part no. (mm) 728-99-KC5 or 7RAQT4-EU tapper (JT2 mount).
3/8"-24 female thread 0 - 10 Collet Shank
0 - 13 insert diameter
728-99-KC5 Composite 0 - 10 Part no. Mount (included)
728-99-KC8 0 - 13 (mm)
R000AR2TM-199 JT1 2U-103-1/4
KC10MM Steel 31427 JT1 31437 3.5 - 6.5
KC13MM 31432 JT1 31436 3.5 - 6.5
7RAQT4-99 JT2 4.5 - 8
Drill Collets 32060 JT1(1) 4U-103-1/2 7 - 12.7
32061 7 - 12.7
1 23
4 (1) 32060 chuck includes 32064 adapter from JT2 to JT1.
5
1 For P33 drill / P45 head 2 For P33 drill / P64 head 3 For P33 drill / P80 head 4 For P33 drill / F80 head
Part no. Collet Ø (mm) Part no. Collet Ø (mm) Part no. Collet Ø (mm) Part no. Collet Ø (mm)
120071 1.0 128250 1.6 128280 2.4 128310 2.0
120072 1.5 128251 1.8 128281 2.6 128311 2.5
120073 2.0 128252 2.0 128283 3.0 128312 3.0
120102 2.2 128253 2.2 128285 3.4 128313 3.5
120106 2.4 128254 2.4 128286 3.6 128314 4.0
120074 2.5 128255 2.6 128287 3.8 128315 4.5
120075 3.0 128256 2.8 128288 4.0 128316 5.0
120105 3.1 128257 3.0 128290 4.4 128317 5.5
120109 3.2 128258 3.2 128291 4.6 128318 6.0
120104 3.25 128259 3.4 128292 4.8 128319 6.5
120113 3.3 128260 3.6 128293 5.0 128320 7.0
120076 3.5 128261 3.8 128294 5.2 128321 7.5
123991 3.6 128262 4.0 128296 5.6 128322 8.0
121552 3.7 128263 4.2 128297 5.8
125783 3.8 128264 4.4 128298 6.0 5 For QA, 1 and 5 Series
120107 3.9 128265 4.0 128299 6.2
120077 4.0 128266 4.8 128300 6.4 Part no. Collet Ø (mm)
120103 4.1 128267 5.0 128301 6.6
120110 4.2 128268 5.2 128302 6.8 43497-40 2.4
120078 4.5 128269 5.4 128303 7.0 43497-30 3.2
128270 5.6 128304 7.2 43497-27 3.6
128271 5.8 43497-20 4.0
128272 6.0 43497-11 4.8
128273 6.2 43497-8 5.0
128274 6.4
