Dewatering Pumps 1 1/2" Pit Boss

Pit Boss Pompes d'épuisement 2" & 3"
Bombas de achique
Pompe per il trasferimento di acque Specialty

Specifications – Especificaciones – Caratteristiche

S PModel 66M170um u6m6pM270 66M320 Sum Pump

1:1 1:1 1:1

302.8 l/min 590.5 l/min 821.3 l/min

bar 1.74 litres 3.86 litres 7.9 litres Dimensions 66M270 66M320 3
bar Dimensiones
8.3 bar 8.3 bar 8.3 bar Dimensioni 650 680
(120 psi) (120 psi) (120 psi) 455 564
66M170 227.5 282
8.3 bar 8.3 bar 8.3 bar A 434 637 771
(120 psi) (120 psi) (120 psi) B 333 410 477
C 166.5 678 828
12.7 mm 19.1 mm 25.4 mm D 297 330 406
E 357 51 70
25.19 kg 33.63 kg 53.67 kg F 506 256 280
G 292
H 44.5
J 286

A G
B H
C

3/4-14 NPTF-1
(66M170...)

11/4 -111/2 NPTF-2
(66M270... & 66M320...)

D F

E 11/2 -11 BSP parallel
(66M170...)
1/2-14 NPTF-1 2-11 BSP parallel
(66M170...) (66M270...)
3-11 BSP parallel
3/4-14 NPTF-2 (66M320...)
(66M270... & 66M320...)

J

Ordering menu • Codification • Codificación • Informazioni per l'ordinazione

6 6M XX 0 –1 X X –C

Model Center section and fluid connection Wetted parts and hardware Seat material Ball material Diaphragm material Series
Modèle Partie moteur et raccordement Partie mouillée et visserie Matière siège Matière bille Matière membrane Série
Modelo Sección central y conexión Sección de fluido y tornillería Material asiento Material bola Material membrana Serie
Modello Sezione centrale e connessione Parti cont. fluido e bulloneria Materiale sede Materiale sfera Materiale membrana Serie

66M Dewatering Pump ATEX certified 0 Aluminium / carbon steel 1 Aluminium 2 Nitrile 2 Nitrile C
Pompe d'épuisement Aluminium / acier carbone 9 Hytrel®
Bomba de achique 17 Aluminium / 1 1/2” BSP Aluminium / acero al carbono C Hytrel® B Santoprene®
Pompa per il 27 Aluminium / 2” BSP Aluminium / acciaio al carbonio
trasferimento di acque 32 Aluminium / 3” BSP E Santoprene®
