TANK MONITORING
INDEX
A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN
CHART IN THE BOX
FUNCTIONING
• OCIO UNIT
• PROBE
Fuel level • 10 MT TUBE
10mm
Measured • INSTRUCTION MANUAL
resolution
Power AC Alarm
Fuel volume
20 litres
Calculated
resolution
Pc
Length up to 50 m Communiction
Fuel % kit
1%
Calculated DETAILS
resolution
BRASS PROBE 2 ALARMS
DIMENSIONS
MATERIALS
• PROBE: BRASS
• TUBE: TECHNOPOLYMER
170
60
180
180
Dimensions expressed in millimeters
TECHNICAL DATA
VISCOSITY VOLTAGE
CODE DESCRIPTION FLUIDS TYPE POWER RS EXIT
cSt AC V./HZ WATT
F0075510D LEVEL INDICATOR OCIO LV / RS OUTPUT A B D O W UP TO 30 230/50 20 AVAILABLE
S
F00755160 LEVEL INDICATOR OCIO LV / 4/20 mA OUTPUT A B D O W S UP TO 30 230/50 20 AVAILABLE
OCIO
TANK LEVEL INDICATORS 181
