FUNCTIONING
CHART IN THE BOX
FULLY AUTOMATIC! • VACUBOX
• INSTRUCTION MANUAL
Suction directly from
car and directly driven
into waste oil
storage tank.
DETAILS
COMPACT DESIGN AUTOMATIC STOPS
DIMENSIONS
VACUBOX FRONT
266 MATERIALS
• PUMP BODY: CAST IRON
• PUMP GEARS: BRONZE
• SHAFT: STEEL
VACUBOX SIDE “A” VACUBOX SIDE “B”
236
246
Dimensions expressed in millimeters
TECHNICAL DATA
FLOW RATE VOLTAGE INLET
CODE DESCRIPTION FLUIDS TYPE
AC V./HZ
L/MIN GPM DC VOLT POWER WATT AMP. MAX. BSP
F00500B00 VACUBOX O 1 - 10 0,25 - 2,5 230/50 350 2 1/2”
VACUBOX
AVAILABLE AT 110-120 V / 60 HZ
ELECTRIC OIL DRAINERS 119
