07178High pressure hoses & hose fittings1SC / 1SN1STCrimp cartridges suitable for different hose modelsPlastics = to skive, ns = not to skiveR+M2SC2ST / 2SNR+M Nr. hoses4 310 05 R+M 1 Bronze ns 10.3 mm 12 mm zinc-plated steel6 310 20 Flexy 300 ns 13.3 mm 25 mm zinc-plated steel6 310 209 Flexy 300 ns 13.3 mm 25 mm stainless steel6 312 09 Flexy 500 s 13.1 mm 30 mm stainless steel10 313 15 2SC 500 bar s 18.3 mm 34 mm zinc-plated steel10 313 29 2SN 500 bar s 18.0 mm 32 mm stainless steel 10 313 19 2SC 500 bar s 16.6 mm 32 mm stainless steel12 313 301 Foodjet ns 23.0 mm 34 mm zinc-plated steel12 313 319 Foodjet ns 22.7 mm 34 mm stainless steelR+M Nr. hoses6 312 05 1SC compact s 12.3 mm 31 mm zinc-plated steel6 312 00 1SN s 13.2 mm 30 mm zinc-plated steel6 312 001 1SN ns 14.4 mm 31 mm zinc-plated steel6 312 09 1SN s 13.1 mm 30 mm stainless steel8 312 10 1SN 210 bar s 14.0 mm 31 mm zinc-plated steel8 312 101 1SN 210 bar ns 16.0 mm 30 mm zinc-plated steel8 312 19 1SN 210 bar s 14.0 mm 31 mm stainless steel8 312 191 1SN 210 bar ns 15.4 mm 30 mm stainless steel8 312 10 1SN 315 bar s 14.0 mm 31 mm zinc-plated steel8 312 101 1SN 315 bar ns 16.0 mm 30 mm zinc-plated steel8 312 19 1SN 315 bar s 14.0 mm 31 mm stainless steel8 312 191 1SN 315 bar ns 17.8 mm 30 mm stainless steel10 313 10 1SN s 16.6 mm 32 mm zinc-plated steel10 313 101 1SN ns 18.3 mm 32 mm zinc-plated steel10 313 19 1SN s 16.6 mm 32 mm stainless steel10 313 191 1SN ns 20.0 mm 34 mm stainless steel10 313 192 1SN ns 19.6 mm 32 mm stainless steel12 313 30 1SN s 20.5 mm 34 mm zinc-plated steel12 313 39 1SN s 19.4 mm 34 mm stainless steel12 313 319 1SN ns 22.7 mm 34 mm stainless steel16 313 40 1SN s 24.0 mm 37 mm zinc-plated steel16 313 401 1SN ns 26.0 mm 37 mm zinc-plated steel16 313 49 1SN s 24.0 mm 37 mm stainless steel20 314 00 1SN s 27.1 mm 43 mm zinc-plated steel20 313 59 1SN s 27.8 mm 43 mm stainless steel20 313 69 1SN ns 30.3 mm 42 mm stainless steel25 313 601 1SN ns 36.8 mm 50 mm zinc-plated steel25 313 659 1SN ns 39.0 mm 48 mm stainless steelR+M Nr. hoses6 312 00 2SC s 13.2 mm 30 mm zinc-plated steel6 312 09 2SC s 13.1 mm 30 mm stainless steel8 312 10 2SC s 14.0 mm 31 mm zinc-plated steel8 312 19 2SC s 14.0 mm 31 mm stainless steel10 313 10 2SC s 16.6 mm 32 mm zinc-plated steel10 313 19 2SC s 16.6 mm 32 mm stainless steel10 313 192 2SC ns 19.6 mm 32 mm stainless steel12 313 39 2SC s 19.4 mm 34 mm stainless steel20 313 69 2SC ns 30.3 mm 42 mm stainless steel25 313 659 2SC ns 39.0 mm 48 mm stainless steelR+M Nr. hoses8 312 10 1ST s 14.0 mm 31 mm zinc-plated steel8 312 19 1ST s 14.0 mm 31 mm stainless steel10 313 10 1ST s 16.6 mm 32 mm zinc-plated steel10 313 19 1ST s 16.6 mm 32 mm stainless steel12 313 30 1ST s 20.5 mm 34 mm zinc-plated steel12 313 39 1ST s 19.4 mm 34 mm stainless steel16 313 40 1ST s 24.0 mm 37 mm zinc-plated steel16 313 49 1ST s 24.0 mm 37 mm stainless steel20 314 00 1ST s 27.1 mm 43 mm zinc-plated steel20 313 59 1ST s 27.8 mm 43 mm stainless steelR+M Nr. hoses6 312 04 2ST / 2SN s 14.2 mm 30 mm zinc-plated steel8 312 20 2ST / 2SN s 15.7 mm 30 mm zinc-plated steel8 312 29 2ST / 2SN s 15.7 mm 30 mm stainless steel8 312 204 2SN ns 18.5 mm 28 mm zinc-plated steel10 313 192 2SN ns 19.6 mm 32 mm stainless steel10 313 192 2ST s 19.6 mm 32 mm stainless steel10 313 20 2ST / 2SN s 18.1 mm 32 mm zinc-plated steel10 313 29 2ST / 2SN s 18.0 mm 32 mm stainless steel10 313 201 2SN ns 18.0 mm 32 mm zinc-plated steel12 313 35 2ST / 2SN s 22.0 mm 34 mm zinc-plated steel12 313 359 2ST / 2SN s 21.0 mm 35 mm stainless steel20 313 69 2SN ns 30.3 mm 42 mm stainless steel20 313 69 2ST s 30.3 mm 42 mm stainless steel25 313 601 2SN ns 36.8 mm 50 mm zinc-plated steel25 313 659 2SN ns 39.0 mm 48 mm stainless steel25 313 659 2ST s 39.0 mm 48 mm stainless steelR+M Nr. hoses5 310 10 RR-120 ns 11.2 mm 17 mm zinc-plated steel5 310 10 RR-200 ns 11.2 mm 17 mm zinc-plated steel6 310 20 6-160 ns 13.3 mm 25 mm zinc-plated steel5 310 10 blupur ns 11.2 mm 17 mm zinc-plated steel6 310 20 CARWASH COMFORT ns 13.3 mm 25 mm zinc-plated steel6 310 209 CARWASH COMFORT ns 13.3 mm 25 mm stainless steel 8 310 807 08 CARWASH COMFORT ns 15.3 mm 30 mm zinc-plated steel12 313 301 blufood ns 23.0 mm 34 mm zinc-plated steel12 313 329 blufood ns 23.0 mm 34 mm stainless steel12 313 329 PUReClean365+%u00aens 23.0 mm 34 mm stainless steelSymbols nominal diameter diameter height material type packing unit
