ACCESSORIES

MMA WELDING KITS
KIT SALDATURA MMA • KIT SOUDAGE MMA • KIT SOLDADURA MMA • MMA SCHWEISSKIT • KIT DE SOLDADURA MMA
2
16mm 3+2 m AX25 - 801096 70mm 4+3 m AX70 - 801106
2
x Infinity 170, 172, 180, 200, 220, Maxima 200, 230, x Linear 500i XD, Linear 530 HD,
Tecnica 171/S, 188 MPGE, 211/S, Artika 270, Technomig 210, 215, 225, 630 HD, Superior 630 CE VRD,
Technomig 223 Treo, Tecnica Tig 190, Technology Tig 182

25mm 4+3 m AX50 - 801081 70mm 4+3 m AX70 - 802666
2
2
x Maxima 270, Infinity Tig 225, Linear 350i, Technology 186 XT, 236 XT, 238 XT, x Superior 400, 630 CE VRD,
Advance Tig 227 XT, Linear 280, Eurarc 410, 422, Superior 250, 320, Electromig Linear 450i, 500i XD,
220, 300, 230 Wave, 330 Wave, Technomig 240 Wave, 260 Dual Synergic, Linear 340, 430 HD, 530 HD,
Technology Tig 222, 230, Superior Tig 251, 252, 311, 322 630 HD
35mm 4+3 m AX50 - 801095
2
x Linear 340, Electromig 400, 450, 550
2
50mm 4+3 m AX50 - 801093
x Eurarc 522, Linear 450i, Linear 430 HD, Superior 400 CE VRD,
Superior Tig 421, 422
CABLES WITH EARTH CLAMP
CABLE S WITH ELECTRODE HOLDERS
2
2
3 m 25mm AX50 - 804122 3m - 16 mm AX25 - 804121
x Technology Tig 182, 222, 230, Superior Tig 251, 252, 311, x Maxima 200, 230, Technomig 215, 223 Treo, Tecnica 190 Tig, Technology Tig 182
322, Superior 250, 320
4 m - 25 mm AX50 - 804123
2
3m 50mm AX50 - 804125 x Maxima 270, Infinity Tig 225, Advance 227 XT, Technomig 240, 260, Electromig
2
x Superior Tig 421, 422, Superior 400, 630, Mastermig 500 220, 300, Electromig 230 Wave, 330 Wave, Superior 400, 630, Techology Tig 230,
222, Superior Tig
2
4 m - 35 mm AX50 - 804124
x Electromig 400, 450, Inverpulse 40.40, 60.30
2
4 m - 70 mm AX70 - 804126
x Electromig 550, Inverpulse 60.40
REMOTE CONTROLS
COMANDI A DISTANZA • COMMANDES A DISTANCE • MANDOS A DISTANCIA • FERNANTRIEBE • CONTROLOS REMOTOS
2 POTENTIOMETERS - 802336 PEDAL - 802017
x Infinity Tig 225, Technology Tig 182, 222, 230, Superior Tig, x Infinity Tig 225, Technology Tig 182, 222, 230, Superior Tig,
Superior 320, 400, 630, Electromig 450, 550, Inverpulse Superior 320, 400, 630
60.30, 60.40

G.R.A. WATER COOLING SYSTEMS
GRUPPI RAFFREDDAMENTO AD ACQUA • GROUPES REFROIDISSEMENT PAR EAU • EQUIPOS DE REFRIGERACION POR AGUA •
WASSERKÜHLUNGSEINHEITEN • SISTEMAS DE REFRIGERAÇÃO DE ÁGUA
P
VPH
LxWxH
50-60Hz W L bar (1 L/min)kW mm kg
G.R.A. 90 230 - 1ph 180 5 3 0,95 255x240x710 15,2
G.R.A. 3300 230 - 1ph 180 4 3 0,6 585x235x185 9
G.R.A. 4000 230 - 1ph 180 4 3 0,6 585x235x185 12
G.R.A. 4500 230 - 1ph 80 1,5 3 0,4 470x190x178 5,9
G.R.A. 90 G.R.A. 3300 G.R.A. 4000
G.R.A. 5500 230 - 1ph 180 4 3 0,6 585x235x185 9
802043 802942 802640 G.R.A. 5505
x Mastermig 500, PTE LCD, x Electromig 330 Wave, x Superior Tig 322, 421, 422 EXTRA POWER 230 - 1ph 180 4 3 0,75 585x235x185 9
PCP LCD Inverpulse 40.40 Wave
AUTOTRANSFORMER (3PH)

AUTOTRASFORMATORE • AUTOTRANSFORMATEUR • AUTOTRANSFORMATOR
• AUTOTRANSFORMADOR • AUTOTRANSFORMADOR
G.R.A. 4500 G.R.A. 5500 G.R.A. 5505
ATT 150 - 802685
802790 804058 804258 (208V-230V → 400V 15kVA)
x Superior Tig 252, 311 x Electromig 450, 550 x Electromig 450, 550 x Superior Tig 322, 421, 422
Synergic, Inverpulse Synergic, Inverpulse
92 60.30, 60.40 60.30, 60.40
