Page 5 - Accessories Airline & Tool Accessories

ARO-Flo Series Air Filters, Regulators & Lubricators

ARO-Flo Filters F354F1-410 Air
(3000 Series) Treatment
ARO-Flo compressed air filters are designed to remove airborne solid
and liquid contaminants which may plug small orifices and hinder F351B1-400 F353D2-311
performance, or cause excessive wear and premature equipment (1000 Series) (2000 Series)
failure. Standard filters are supplied with 5-micron elements. Coalescing filter
40-micron elements can be purchased and installed separately. F352C1-411 with service indicator
Coalescing models are capable of removing oil aerosols and (1500 Series) as standard
particles down to 0.3 micron.
All filters have aluminium body, nitrile seals and acetal baffle. F353D1-400
Drain: brass + nitrile (manual), acetal (automatic). Filter insert
from Polyethylene (or HEPA paper + felt for coalescing).

Part Series Max. Bowl material
no. flow and drain type
(l/min)

Standard Air Filters Series
Port size
F351B1-400 1000 1/4" BSP 1 380 Polycarbonate / Manual Service indicator
F351B1-421 Metal / Automatic Filter element
Bowl option Models not listed in the table are
F352C1-400 1500 3/8" BSP 3 030 Polycarbonate / Manual Drain option available on special request.
F352C1-411 Metal / Automatic Not all combinations available.

F353D1-400 2000 1/2" BSP 5 580 Polycarbonate / Manual Series Filter element
F353D1-411 3/4" BSP 6 110 Metal / Automatic 1 = 1000 Series 2 = 1500 Series 3 = 0.3 micron coalescing
F353E1-400 3 = 2000 Series 4 = 3000 Series 4 = 5 micron
F353E1-411 Polycarbonate / Manual
Metal / Automatic Port size A = 1/8" BSP Bowl option
1 = 1/8" NPT B = 1/4" BSP 0 = Polycarbonate with guard
F354E1-410 3000 3/4" BSP 8 150 Metal / Manual 2 = 1/4" NPT C = 3/8" BSP
F354F1-410 1" BSP 9 990 Metal / Manual 3 = 3/8" NPT D = 1/2" BSP (without guard on 1000 Series)
4 = 1/2" NPT E = 3/4" BSP 1 = Metal with sight glass
Coalescing Air Filters with Service Indicator 5 = 3/4" NPT F = 1" BSP
6 = 1" NPT (not available on 1000 Series)
2 = Metal without sight glass
F353D2-311 2000 1/2" BSP 2 600 Metal / Automatic Service indicator
1 = None Drain option
F354E2-311 3000 3/4" BSP 3 740 Metal / Automatic 2 = Mechanical (for coalescing) 0 = Manual
F354F2-311 1" BSP 3 960 Metal / Automatic 1 = Automatic
for 2000 & 3000 Series only

ARO-Flo Regulators R371B1-600 R372C1-600
(1000 Series) (1500 Series)
ARO-Flo regulators provide controlled, consistent air pressure as
required for pneumatic equipment. Rigid aluminium body with nitrile R373D1-600 R374E1-600
O-rings, acetal knob, steel springs, nylon/polycarbonate gauge cover (2000 Series) (3000 Series)
and 1/8" gauge port.
Diaphragm: Nitrile + nylon (nitrile + acetal for Series 1000). R373D1-600
Regulator valve: Nitrile + nylon (brass + nitrile for Series 1000).
Panel nut included with regulator. Series
Port size
Alternative springs are offered to suit different pressure requirements (see page 8). Gauge / pressure range
Non-relieving regulators can be offered if venting of downstream overpressure is Relieving as standard
undesirable. Please use service kits listed on accessories / spare parts page to convert Control option (0 = standard)
from relieving to non-relieving models.

Part Series Max. Pressure Models not listed in the table are
no. flow range available on special request.
(l/min) Not all combinations available.
0 - 9.6 bar
Standard Air Regulators 1670 (0 - 140 psig) Series Gauge / pressure range
3200 Max. inlet pressure 1 = 0-9.6 bar (0-140 psig) no gauge.
R371B1-600 1000 1/4" BSP 5940 17.2 bar (250 psig) 1 = 1000 Series 2 = 1500 Series
5940 3 = 2000 Series 4 = 3000 Series 2 = 0 - 4 bar (0 - 60 psig) no gauge.
8210
R372C1-600 1500 3/8" BSP 8210 Port size 3 = 0.7 - 14 bar (10 - 200 psig) no
gauge, on 2000 & 3000 Series
R373D1-600 2000 1/2" BSP 1 = 1/8" NPT A = 1/8" BSP only.
R373E1-600 3/4" BSP 2 = 1/4" NPT B = 1/4" BSP
3 = 3/8" NPT C = 3/8" BSP 4 = 0 - 2 bar (0 - 30 psig) no gauge.
R374E1-600 3/4" BSP 4 = 1/2" NPT D = 1/2" BSP
R374F1-600 3000 1" BSP 5 = 3/4" NPT E = 3/4" BSP 6 = 0 - 9.6 bar (0-140 psig) with
6 = 1" NPT F = 1" BSP flush mount gauge = standard.

Ingersoll Rand Accessories 5
