BL4000 BL7000

Equipment: Equipment:
Two Schuko-Sockets. One CEE 16A-3ph. Socket, one Schuko-Socket.
Automatic shut down if low oil level is detected. Voltmeter, Operating time counter,
Automatic shut down if low oil level is detected.

530 mm 530 mm

740 mm 500 mm 740 mm 500 mm

BL4000 E–S/SHBA BL7000 ED–S/SHBA
Order-No.: 986253 Order-No.: 986257
GTIN: 4038469100081 GTIN: 4038469100098

Alternator Synchronous Alternator Synchronous
El. capacity: 1~ cos φ 1,0 4000 VA El. capacity: 3~ cos φ 1,0 7500 VA
Voltage 1~ 230 V El. capacity: 1~ cos φ 1,0 4000 VA
Max. sum. current 1~ 17,4 A Voltage 3~ 400 V
Current 1~ (Schuko) 16 A Voltage 1~ 230 V
Frequency 50 Hz Current 3~ 10,9 A
Safety class alternator IP 23 Max. sum. current 1~ 17,5 A
Engine type B&S Series 1450 Frequency 50 Hz
Number of cylinders 1 Safety class alternator IP 23
Rotation-speed (3000 1/min) 3000 U min -1 Engine type B&S Series 2100
Fuel type Gasoline Number of cylinders 1
Engine oil capacity 0,8 l Rotation-speed (3000 1/min) 3000 U min -1
Engine power 5,8 kW Fuel type Gasoline
Cooling engine/alternator Air / Air Engine oil capacity 1,1 l
Tank capacity 3,2 l Engine power 7,7 kW
Operating time: full load/half load 1,5 / 2,5 h Cooling engine/alternator Air / Air
Weight 56,5 kg Tank capacity 6,6 l
Dimensions L x W x H 740 x 500 x 530 mm Operating time: full load/half load 2,8 / 3,4 h
Noise power level L WA 98 dB(A) Weight 75 kg
Noise pressure (10m) 70 dB(A) Dimensions L x W x H 740 x 500 x 530 mm
Noise power level L WA 99 dB(A)
Noise pressure (10m) 71 dB(A)
