Page 131 - Piusi_Lube

B
FILTRATION
FILTRATION FLUID TANK HOSE REELS ACCESSORIES MERCHANDISE
MONITORING F MONITORING B
INDEX
F
A A C Ad B A D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN
C
D A
DIMENSIONS
CHART IN THE BOX
B D
F B • FILTER CARTRIDGE
• INSTRUCTION MANUAL
F
C
A
C A
D
A B C D B F
(MM) (MM) (MM) (MM) D
OIL FILTERS F B
F0777200A - 100 160 98 - OIL FILTERS
F0914900A - 171 236 132 - F
F09149020 - 171 236 132 - DETAILS
C
F00611000 145 - - 98 3/4” BSP A
F09359000 180 - - 132 1”1/4 BSP C
F09359010 180 - - 132 1”1/4 BSP D A
F16483010 139 - - 93 -
F14528000 - 100 - - 3/4” BSP D
F15743000 - 171 - - 1”1/2-16 UNF FILTER HEAD REPLACEABLE CARTRIDGE
1”1/4 BSP

DIMENSIONS

MATERIALS
• FILTER HEAD: CASTING ALUMINIUM
• CARTRIDGE: SAP/PET
• SEAL: VULCANIZED RUBBER

TECHNICAL DATA
FLOW RATE INLET / OUTLET EFFICIENCY MICRO WORKING
PRESSURE
WATER
CODE DESCRIPTION FLUIDS TYPE ABSORBING
L/MIN GPM BSP ß µ m BAR
OIL FILTERS
F0777200A 60 L/MIN FILTER WITH HEAD B D G O 60 15,9 1” NO 2 10 12
F09149020 100 L/MIN FILTER WITH HEAD B D G O 100 26,4 1” NO 2 5 12
OIL FILTER CARTRIDGE
F09359010 CARTRIDGE 100 L/MIN B D G O 100 26,4 - NO 2 5 12
F16483010 KIT CARTRIDGE 60 L/MIN 15 (PCS) B D G O 60 15,9 - NO 2 10 12
FILTER HEAD
F14528000 FILTER HEAD 3/4 BSP 60 L/MIN - - - 1” NO - - -
OIL FILTERS

FILTERS 131
