CHART IN THE BOX

• K600/3 METER
• INSTRUCTION MANUAL

DETAILS

RESET / CALIBRATE BUTTON OVAL GEAR
TYPE OF FLUID OIL SAE 10W40
TEMPERATURE 20 °C
DIMENSIONS

ALLUMINIUM BODY
MATERIALS
68 77,4
• BODY: ALLUMINIUM
• GEARS: TECHNOPOLYMER

94
41,5

76 73

112 80

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW RATE WORKING PRESSURE BATTERY
INLET
INLET
CODE DESCRIPTION FLUIDS TYPE INCLUDED FLANGE OUTLET FILTER
L/MIN GPM BAR PSI NO. 2 2X1,5V
METER
F00496A20 K600/3 METER ¾” BSP OIL A O 6 - 60 1,58 - 1,58 70 994 YES YES 3/4” BSP YES
PULSER
F00472A20 K600/3 PULSER ¾” BSP OIL A O 6 - 60 1,58 - 1,58 70 994 NO YES 3/4” BSP YES
K600/3
UPON REQUEST AVAILABLE IN NPTF VERSION AND DISPLAY IN GALLON/QUARTER OR PRINT

ELECTRONIC METERS 71
