CHART IN THE BOX

• K600/4 METER
• INSTRUCTION MANUAL

DETAILS

RESET / CALIBRATE BUTTON OVAL GEAR
TYPE OF FLUID OIL SAE 80W90
TEMPERATURE 20 °C
DIMENSIONS

ALLUMINIUM BODY
MATERIALS
28 112 28 90 • BODY: ALLUMINIUM
• GEARS: TECHNOPOLYMER

83,9 119,5

168 62

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW RATE WORKING PRESSURE BATTERY
INLET
INLET
CODE DESCRIPTION FLUIDS TYPE INCLUDED FLANGE OUTLET FILTER
L/MIN GPM BAR PSI NO. 2 2X1,5V
METER
00049700A K600/4 METER 1 ½” BSP A O 15 - 150 3,9 - 39 20 284 YES YES 1 1/2” BSP YES
PULSER
000473000 K600/4 PULSER 1 ½” BSP A O 15 - 150 3,9 - 39 20 300 NO YES 1 1/2” NPT YES
K600/4
UPON REQUEST AVAILABLE IN NPTF VERSION AND DISPLAY IN GALLON/QUARTER OR PINT

ELECTRONIC METERS 75
