CHART IN THE BOX

• K33 / K44 METER
• INSTRUCTION MANUAL

DETAILS

NUTATING DISK SYSTEM 4 FLOW DIRECTIONS
TYPE OF FLUID DIESEL
TEMPERATURE 16 °C
DIMENSIONS

MECHANICAL COUNTER
MATERIALS
• NUTATING DISK CHAMBER: TECHNOPOLYMER
• BODY: ALLUMINIUM
100 128

104 ø34,1 1” bsp

176 62

Dimensions expressed in millimeters

TECHNICAL DATA
PRESSURE
FLOW
INLET
CODE DESCRIPTION FLUIDS DIRECTION FLOW RATE WORKING PULSER OUTLET
TYPE
L/MIN GPM BAR PSI P/L (P/GAL)
K33 METER
000550160 K33 VER. A O 20-120 5-32 10 142 YES 1” BSP
000551160 K33 VER. B O 20-120 5-32 10 142 YES 1” BSP
000557000 K33 VER. C O 20-120 5-32 10 142 YES 1” BSP
000558000 K33 VER. D O 20-120 5-32 10 142 YES 1” BSP
K44 METER
000560160 K44 VER. A O 20-120 5-32 10 142 YES 1” BSP
000561020 K44 VER. B O 20-120 5-32 10 142 YES 1” BSP
000562020 K44 VER. C O 20-120 5-32 10 142 YES 1” BSP
000563020 K44 VER. D O 20-120 5-32 10 142 YES 1” BSP
K33 / K44
UPON REQUEST AVAILABLE IN NPTF VERSION AND DISPLAY IN GALLON/QUARTER OR PINT

MECHANICAL METERS 83
