10 Lances

ST-175 Foam & Clean
The change-over lance ST-175 Foam & Clean is the ideal Appropriate nozzle sizing at chemical injector and ST-175 allows
accessory for Suttner's foam injector line. The innovative change- changing from foaming to rinsing right at the lance. ST -175
over technology allows to direct the full flow into either one or Foam & Clean is compatible to ST-160 / ST-164 / ST-166 / ST-167.
the other outlet pipe just by turning the hand wheel at the inlet.
Due to ST -175's changeable air injector nozzles the lance can be
In one position of the hand wheel the flow is directed thru an driven with all pressure washers with flow rates from 5 to 25 l /
ST-75 foam head for foaming. After changing over the full flow min.
is directed thru the other pipe and a regular spray nozzle for Nozzles with integrated jet former are required (page 337).
rinsing.

K
Twin foam lance with vented handle ST-9 380 mm, change-over valve Twin foam lance with vented handle ST-9 205 mm, change-over valve
ST-58, nozzle protector ST-10 without nozzle and foam head ST-75 without ST-58, ergonomic swivel screw coupling, nozzle protector without tip and
nozzle. A foam injector is required. foam head ST-75.1 without nozzle. A foam injector is required.
Max. 350 bar / 45 l/min / 100 °C Max. 350 bar / 45 l/min / 100 °C
R+M Nr. R+M Nr.
200 175 400 1/4" F - 650 mm 200 175 411 M22 F - 420 mm

Twin foam lance with vented handle ST-9 380 mm, change-over lance Twin foam lance with vented handle ST-9 205 mm, change-over valve
with 1/4" M and nozzle protector ST-10 without nozzle. ST-58, nozzle protector without tip and foam head ST-75.1 without nozzle.
Max. 350 bar / 45 l/min / 100 °C A foam injector is required.
Max. 350 bar / 45 l/min / 100 °C
R+M Nr. R+M Nr.
200 175 510 1/4" F - 650 mm 200 175 412 1/4" F - 420 mm

Twin foam lance with vented handle ST-9 380 mm, change-over valve Twin foam lance with vented handle ST-9 205 mm, change-over valve ST-
ST-58, nozzle protector ST-10 without nozzle and foam head ST-75 with 58, nozzle protector ST-10 without nozzle and foam head ST-75.1 without
nozzle. A foam injector is required. nozzle. A foam injector is required.
Max. 350 bar / 45 l/min / 100 °C Max. 350 bar / 45 l/min / 100 °C
R+M Nr. R+M Nr.
200 175 430 M22 F 1.9 650 mm 200 175 414 1/4" F - 420 mm
200 175 431 M22 F 2.1 650 mm

Symbols inlet outlet length material nozzle
