Floor cleaner 12

Floor cleaner Mosmatic

Surface cleaner FL-AHY 520 Mosmatic Roof cleaner DR-520 Mosmatic

Completely stainless steel. Roof cleaner with an additional frame for
highest stability. Adjustable in width of up to 90 mm and in height of up to
33 mm. Including a safety loop for the safety rope with clippers. The use of
the ST-550 foot valve is recommended. 4 industrial castors (125 mm).
Max. 2,400 l/h / 120 °C

R+M Nr.
108 809 72 520 mm 3/8" F max. 350 bar
108 809 73 520 mm 3/8" F max. 500 bar
Completely stainless steel. Surface cleaner with an additional frame
for highest stability. A height adjustable housing including a device for The accident prevention regulations of the Employer's Liability
extraction. Foldable handle bar for space saving and reasonable transport.
2 nozzles are required. Suitable for 50 mm suction hose. 4 industrial castors Insurance Association regarding "the use of high pressure cleaner"
(100 mm). Max. 2,400 l/h / 120 °C (BGV D15) & "tasks with liquid jets" (BGV D26) in addition to DIN EN
60335-2-79 and DIN EN 1829-1 prescribe that manually guided spray
R+M Nr. units (like roof ceaners) shall be provided with a manually-actuated
108 809 71 520 mm 1/4" F max. 500 bar
control for release of the cleaning solution.
Surface cleaner FL-SAR 300 Mosmatic
Surface and underbody cleaner Hurricane Flip, 2 - in - 1 Mosmatic
The Mosmatic Hurri-
cane Flip can be used new
as surface cleaner and 100
underbody wash, all in
one unit.
The Hurricane Flip can
be converted from a Toggle joint:
floor cleaner to an un- Thanks to the low
dercarriage cleaner in profile, the vehicle
just a few simple steps. does not need to be
The proven toggle joint lifted on a platform
makes easy and effert- to be cleaned.
less cleaning possible.
Positioned on the side
of the housing, this
special design enables
cleaning under the
vehicle.
With 3 stainless steel
castors ø 60 mm.
Surface cleaner AQUA with recovery. Complete with integrated suction Incl. 2 high-pressure
system, spray gun and nozzles. Recovery Port: 40 mm nozzles ex works for e.g.
Designed for 150 bar / 15 l / min. The black anodized aluminum suction 15 l / min. at 130 bar or
device collects the dirty water via a Venturi and double housing system.It 18 l/min. at 175 bar.
can then be led away via a commercially available suction hose.
The use of a vacuum system is no longer needed. Max. 275 bar / 120 °C.
Max. 275 bar / 120 °C.
Not suitable for paved areas.
R+M Nr. R+M Nr.
108 782 43 300 mm 3/8" F max. 275 bar 108 786 02 300 mm 3/8" F max. 275 bar

315
