ADSORPTIONSTØRRERE TRYKLUFT
PH 2 - 45 HE
Model Kapacitet Max. tryk Tilslutning Spænding Vægt Dimensioner Trykdugpunkt Best. nr.
l/min. m /t bar V kg LxBxH (mm) °C LUFTBEHANDLING
3
PH 2 HE 60 4 16 1/4” 230/1/50 7 106x197x540 -40 8102337824
PH 4 HE 120 7 16 1/4” 230/1/50 9 106x197x720 -40 8102337907
PH 6 HE 180 11 16 1/4” 230/1/50 11 106x197x855 -40 8102337980
PH 11 HE 300 18 16 1/2” 230/1/50 19 149x320x640 -40 8102338020
PH 15 HE 420 25 16 1/2” 230/1/50 22 149x320x725 -40 8102338061
PH 20 HE 600 36 16 1/2” 230/1/50 25 149x320x875 -40 8102338103
PH 25 HE 720 43 16 1/2” 230/1/50 29 149x320x1015 -40 8102338145
PH 35 HE 1020 61 16 1/2” 230/1/50 35 149x320x1270 -40 8102338186
PH 45 HE 1320 73 16 1/2” 230/1/50 44 149x320x1505 -40 8102338228
TILBEHØR TIL PH 2-45 HE
DYSE FOR ”PURGE” LUFT VÆGBESLAG
Til model Best. nr. Til model Best. nr.
PH 2 HE 8092345980 PH 2-6 HE 2901990238
PH 4 HE 8092345982 PH 11-45 HE 2901990239
PH 6 HE 8092345984
TRYKDUGPUNKT KONTROL-
PH 11 HE 8092345985
KIT INKL. SENSOR
PH 15 HE 8092345986
PH 20 HE 8092345987 Til model Best. nr.
PH 2-45 HE 8092345969
PH 25 HE 8092345988
PH 35 HE 8092345989
PH 55 - 550 HE PH 45 HE 8092345990
PH 2 - 45 HE
PRODUKTKATALOG 2023 85
