TECHNICAL SPECIFICATIONS

• Water-cooled frequency-controlled 0.5 – 6 kW electric • CNG tanks (2x 75 l) with gas pressure regulators - gas
motor working on low-voltage (48 V) so no conversion pressure regulation circuit with the necessary safety and
losses. detection devices
• Environmentally friendly • Radial high pressure pump with 3 ceramic plungers and
• Exceptionally low noise production stainless steel valves
• Maintenance-free • Washable water filter
• Lower and 40% less expensive energy consumption • Pressure-free starting
• The 25 kW-48 V Li-ion battery with BMS system was fully • Auto-stop system stops the engine after 30 min. without
custom-made and tailored for the cleaning work. spraying activity
• Efficient, compact and lightweight long life LI-ion • 400 l built-in water tank (only for TG and S version)
battery with high energy density/kg • Pressure relief up to <25 bar with sealed gun → safety
• Easy to recharge at any time (any 230 V socket) • Electronic pressure and flow regulation via electronic
• The battery supplies its power as efficiently as possible speed engine governor
• Long working time: up to six hours of high pressure • Automatic idling → less consumption (*)
cleaning and 11 hours with the optional steam function • Trailer version: galvanized trailer fitted with support
(SF) or weed killing function (WK) and swivel wheel, an ALKO chassis with rotation casted
• 70 kW GreenBoiler-CNG polyethylene tank and polyester housing
• Control 24 VDC and burner 230 VAC • Required towing capacity = 1900 kg
• Electronic level indication with low level monitoring for the
water tank and CNG tanks.
• Battery percentage shown on the display

MODELS

code description bar l/h °C V - kWh kW kW l mm kg
99° on surface
1.134.E.278 JMB-ME 170/18 TG AK WK (+) < 30 (WK-function) / 600 (WK-function) / (WK-function) / Li-Ion battery - 48 V- 0,5 - 6 70 400 3500 x 1800 x 1750 - 060
25 kWh - (BMS)
up to 170 (HP)
up to 1080 (HP)
110 (HP)
99° on surface
1.134.E.328 JMB-ME 200/15 TG AK WK (+) < 30 (WK-function) / 600 (WK-function) / (WK-function) / Li-Ion battery - 48 V- 0,5 - 6 70 400 3500 x 1800 x 1750 1410 045
up to 200 (HP)
up to 900 (HP)
25 kWh - (BMS)
110 (HP)

STANDARD EQUIPMENT OPTIONAL EQUIPMENT
Code Item description Code Item description
1.216.729.xxxxx Single stainless steel lance with high pressure nozzle and rota- 1.234.247 (DH) Supplement for pressure-retaining valve (to replace the
ting quick coupling (≤ 250 bar) standard pressure-free)
1.211.5xx High pressure gun with swivel → large manoeuvrabilty of the 1.234.150 (TT) Supplement for track & trace system (JMB-MG/ME)
wash gun 1.890.000 Yearly subscription for the activation of the Track & Trace option.
1.234.290 Transfer pump - JMB-ME (TP)
1.234.074.(RAL)xxxx (COL) Supplement for protective housing in your chosen RAL
1.230.297 35 cm - Stainless steel WK-lance with temperature sticker for colour (Note: when ordering, please specify your chosen RAL
weed control colour)
1.230.312 One set of large removable wheels for WK-lance 1.234.07x (COL) Supplement for protective housing in a DiBO RAL colour:
• (WH) RAL9016 - white
• (BK) RAL 9017 - black
• (BU) RAL 5002 - blue
• (OG) RAL 2009 - orange
(Note: when ordering, please specify one of the following RAL
colours)

1.230.297 1.230.312 WK-lance
