TECHNICAL SPECIFICATIONS

• Industrial 18 kW water-cooled Kubota motor running on • Washable water filter
CNG gas with heat recovery system. The motor’s heat • Pressure-free starting
recovery system means less energy consumption is • Automatical stop system after 30 minutes of inactivity
needed to bring the cleaning water up to temperature • Trailer version: galvanized trailer fitted with support
• Optimal CNG motor safety, being fitted with a CAN BUS- and swivel wheel, an AL-KO chassis with rotation casted
controlled ECU and DiBO control unit. polyethylene tank and polyester housing
• 70 kW GreenBoiler-CNG • Built-in 450 l water tank
• Control 24 VDC and burner 230 VAC • Pressure relief up to <25 bar with sealed gun → safety
• CNG tanks (2x 75 l) with gas pressure regulators - gas • Electronic pressure and flow regulation via electronic
pressure regulation circuit with the necessary safety and speed engine governor
detection devices • Automatic idling → less consumption
• Electronic level indication with low level monitoring for the • Trailer version: galvanized trailer fitted with support
water tank and CNG tanks. and swivel wheel, an AL-KO chassis with rotation casted
• Radial high pressure pump with 3 ceramic plungers and polyethylene tank and polyester housing
stainless steel valves • Required towing capacity = 1800 kg

MODELS

Code Description bar l/h °C kW kW l mm kg
1.134.G678 JMB-MG 350/18 TG AK WK (+) < 30 (WK-function) / 600 (WK-function) / 99° on surface (WK-function) 18 70 450 3500 x 1800 x 1750 1210 040
up to 350 (HP) up to 1080 (HP) / 110 (HP)

STANDARD EQUIPMENT OPTIONAL EQUIPMENT

Code Item description Code Item description
1.208.749.xxxxx Single lance with rotating high pressure nozzle → powerful water 1.234.247 (DH) Supplement for pressure-retaining valve (to replace the
jet (only on 350 bar) standard pressure-free)
1.211.5xx High pressure gun with swivel → large manoeuvrabilty of the 1.234.150 (TT) Supplement for track & trace system (JMB-MG/ME)
wash gun 1.890.000 Yearly subscription for the activation of the Track & Trace option.
1.234.290 Transfer pump - JMB-MG/ME (TP)
1.234.074.(RAL)xxxx (COL) Supplement for protective housing in your chosen RAL
1.230.297 35 cm - Stainless steel WK-lance with temperature sticker for colour (Note: when ordering, please specify your chosen RAL
weed control colour)
1.230.312 One set of large removable wheels for WK-lance 1.234.07x (COL) Supplement for protective housing in a DiBO RAL colour:
• (WH) RAL9016 - white
• (BK) RAL 9017 - black
• (BU) RAL 5002 - blue
• (OG) RAL 2009 - orange
(Note: when ordering, please specify one of the following RAL
colours)

1.230.297 1.230.312 WK-lance
15
