CHART IN THE BOX

• PANTHER AC PUMP
• INSTRUCTION MANUAL

DETAILS

VANE ROTOR INTEGRATED FILTER
TYPE OF FLUID DIESEL
TEMPERATURE 20°C
DIMENSIONS

186 PANTHER 72
236 155 PANTHER 56 MATERIALS

• BODY: CAST IRON
• ROTOR: SINTERED STEEL
• VANES: TECHNOPOLYMER
• SHAFT: STEEL
171

100 > MAX 6M (20FT),
PUMP > SUCTION HOSE Ø 1” MIN, TANK
> MAX SUCTION HEIGHT:
Dimensions expressed in millimeters - 2M (7FT) W/O NON RETURN VALVE
- 4M (14FT) W NON RETURN VALVE
TECHNICAL DATA
INLET
DUTY
FLOW RATE VOLTAGE OUTLET CICLE
INLET
FLANGE
CODE DESCRIPTION FLUIDS L/MIN GPM SINGLEPHASE THREEPHASE POWER MAX. RPM BSP CONNECTION BYPASS FILTER MINUTE
VALVE
AMP.
TYPE
MOTOR V./HZ
MOTOR V./HZ
WATT
PANTHER 56
F00730000 PANTHER 56 230/50 D 56 15 230/50 - 350 3 2900 1” - YES YES
000731000 PANTHER 56 230/60 D 70 18 230/60 - 500 3,9 3400 1” - YES YES
000733000 PANTHER 56 400/50 D 56 15 - 400/50 500 1,3 2900 1” - YES YES
PANTHER 72
000732000 PANTHER 72 230/50 D 72 19 230/50 - 500 4,2 2900 1” YES YES YES
000735000 PANTHER 72 400/50 D 72 19 - 400/50 500 1,6 2900 1” YES YES YES
PANTHER 90
F0073302A PANTHER 90 230/50 D 90 23,8 230/50 - 700 4,9 2900 1” YES YES YES 30
UPON REQUEST IT IS AVAILABLE WITH DIFFERENT VOLTAGES AND 60 HZ FREQUENCY.
( ) EXCEPT PANTHER 90 PANTHER AC
AC PUMPS 103
