CHART IN THE BOX

• EX50 / EX75 DC PUMP
• FLANGED CONNECTIONS
• INSTRUCTION MANUAL

DETAILS

ON/OFF SWITCH FLANGED CONNECTIONS
TYPE OF FLUID GASOLINE
TEMPERATURE 20#C
DIMENSIONS

MATERIALS
• BODY: CAST IRON
• ROTOR: SINTERED STEEL
• VANES: PPS
• SEAL: VITON
181 • SHAFT: STEEL

141 252

> MAX 6M (20FT),
> SUCTION HOSE Ø 1” MIN,
PUMP > MAX SUCTION HEIGHT: TANK
- 2M (7FT) W/O NON RETURN VALVE
- 4M (14FT) W NON RETURN VALVE
Dimensions expressed in millimeters

TECHNICAL DATA
FLOW RATE VOLTAGE DUTY CICLE OUTLET
CODE DESCRIPTION FLUIDS L/MIN GPM VOLT/HZ POWER AMP. MINUTES RPM BSP
TYPE
AC
WATT
MAX.
F00371000 EX50 12V DC ATEX D G K 50 13 12 250 21 30 2700 1”
F00380000 EX75 12V DC ATEX D G K 75 19,8 12 240 20 30 2700 1”
( ) UPON REQUEST IT IS AVAILABLE WITH DIFFERENT VOLTAGES AND 60 HZ FREQUENCY. THE PUMP CAN BE USED ONLY WITH THE
FOLLOWING FLUIDS: DIESEL, KEROSENE, PETROL, PETROL ALCOHOL MIXED MAX 15% , AVGAS 100/100LL, JET A/A1 - ASPEN 2/4 EX50 / EX75 DC
ATEX DC PUMPS 101
