INDEX

A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

CHART IN THE BOX

• CUBE B.SMART DISPENSER
• AUTOMATIC NOZZLE
• DELIVERY HOSE
• DRIVER ACCESS ADD-ON
• INSTRUCTION MANUAL

DETAILS

SHUTTER B.SMART MOBILE APP
TYPE OF FLUID DIESEL
TEMPERATURE 20°C
DIMENSIONS
413 500
345 314 B.SMART CLOUD SOFTWARE
MATERIALS
341
• PUMPS:
PANTHER AC PAG. 102
PANTHER DC PAG. 114
1368 • METER:
K600/3 PAG. 134
• NOZZLE:
AUTOMATIC NOZZLE PAG. 158
Dimensions expressed in millimeters
336 281
TECHNICAL DATA
FLOW RATE VOLTAGE PUMP METER NOZZLE FILTER INLET HOSE
CODE DESCRIPTION FLUIDS L/MIN GPM AC V./HZ POWER AMP. TYPE TYPE TYPE FILTER BSP LENGTH Ø
TYPE
H20
DC VOLT
WATT
MAX.
AC VERSION
F00598000 CUBE 70 230V B.SMART 10 DIVERS D 70 18 230 V 50 HZ 900 W 4,2 A PANTHER 72 K600/3 A60 NO 1'' 4M 25MM
F00598020 CUBE 70 B.SMART 230 V 20 DIVERS D 70 18 230 V 50 HZ 900 W 4,2 A PANTHER 72 K600/3 A60 NO 1'' 4M 25MM
F00598040 CUBE 70 B.SMART 230 V 50 DIVERS D 70 18 230 V 50 HZ 900 W 4,2 A PANTHER 72 K600/3 A60 NO 1'' 4M 25MM
F00598010 CUBE 90 230V B.SMART 10 DIVERS D 90 24 230 V 50 HZ 900 W 4,9 A PANTHER 90 K600/3 A120 NO 1'' 4M 25MM
F00598030 CUBE 90 B.SMART 230V 20 DIVERS D 90 24 230 V 50 HZ 900 W 4,9 A PANTHER 90 K600/3 A120 NO 1'' 4M 25MM
F00598050 CUBE 90 B.SMART 230V 50 DIVERS D 90 24 230 V 50 HZ 900 W 4,9 A PANTHER 90 K600/3 A120 NO 1'' 4M 25MM
DC VERSION
F00598A00 CUBE 12 V B.SMART • 10 DRIVERS D 56 15 12 V - 300 35 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
F00598A20 CUBE 12 V B.SMART • 20 DRIVERS D 56 15 12 V - 300 35 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
F00598A40 CUBE 12 V B.SMART • 50 DRIVERS D 56 15 12 V - 300 35 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
F00598A10 CUBE 24 V B.SMART • 10 DRIVERS D 70 18 24 V - 420 25 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
F00598A30 CUBE 24 V B.SMART • 20 DRIVERS D 70 18 24 V - 420 25 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
F00598A50 CUBE 24 V B.SMART • 50 DRIVERS D 70 18 24 V - 420 25 PANTHER DC K600/3 A60 NO 1'' 4M 25MM
CUBE B.SMART

B.SMART DISPENSERS 15
