CHART IN THE BOX

• SELF SERVICE B.SMART DISPENSER
• DELIVERY HOSE
• AUTOMATIC NOZZLE
• DRIVER ACCESS ADD-ON
• INSTRUCTION MANUAL

DETAILS

SHUTTER B.SMART MOBILE APP
TYPE OF FLUID DIESEL
TEMPERATURE 20°C
DIMENSIONS
457 360 457 360
B.SMART CLOUD SOFTWARE WATER CAPTOR FILTER (pag. 170)
280 280
MATERIALS

506 506 • PUMPS: PAG. 102/106
PANTHER 72 / E120
990 • METER:
1387 K600/3 PAG. 134
• NOZZLE:
AUTOMATIC NOZZLE PAG. 158
360
280 • FILTER:
WATER CAPTOR PAG. 170

280 360

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW RATE VOLTAGE PUMP METER NOZZLE FILTER INLET HOSE
CODE DESCRIPTION FLUIDS L/MIN GPM AC V./HZ POWER AMP. TYPE TYPE TYPE FILTER BSP LENGTH Ø
TYPE
H20
WATT
MAX.
DC VOLT
F00748010 SELF SERVICE 70 230V B.SMART 10 DRIVERS D 70 18 230 V 50 HZ 550 W 3,3 A PANTHER 72 K600/3 A120 30 µM 1 1/2'' 4M 25MM
F00748040 SELF SERVICE 70 230V B.SMART 20 DRIVERS D 70 18 230 V 50 HZ 550 W 3,3 A PANTHER 72 K600/3 A120 30 µM 1 1/2'' 4M 25MM
F00748060 SELF SERVICE 70 230V B.SMART 50 DRIVERS D 70 18 230 V 50 HZ 550 W 3,3 A PANTHER 72 K600/3 A120 30 µM 1 1/2'' 4M 25MM
F00748000 SELF SERVICE 100 230V B.SMART 10 DRIVERS D 90 24 230 V 50 HZ 1150 W 5,7 A E120 K600/3 A120 30 µM 1 1/2'' 4M 25MM
F00748030 SELF SERVICE 100 230V B.SMART 20 DRIVERS D 90 24 230 V 50 HZ 1150 W 5,7 A E120 K600/3 A120 30 µM 1 1/2'' 4M 25MM
F00748070 SELF SERVICE 100 230V B.SMART 50 DRIVERS D 90 24 230 V 50 HZ 1150 W 5,7 A E120 K600/3 A120 30 µM 1 1/2'' 4M 25MM
SELF SERVICE B.SMART
