FILTRATION TANK MONITORING HOSE REEL ACCESSORIES MERCHANDISE
INDEX

A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

CHART IN THE BOX

• EX50 PUMP
• TELESCOPIC SUCTION PIPE
• DELIVERY HOSE
• WATER CAPTOR FILTER
• A60 ATEX NOZZLE
• 2” CONNECTOR
• K33 ATEX METER (ON SELECTED VERSION)
• INSTRUCTION MANUAL

DETAILS

2” CONNECTOR INTEGRATED FILTER
TYPE OF FLUID DIESEL
TEMPERATURE 20/23°C
DIMENSIONS

244 206 BENDING PROTECTION

COMPONENTS
MATERIALS
• PUMP:
EX50 PAG. 94
• METER:
345 K33 ATEX PAG. 128
• NOZZLE:
A60 ATEX PAG. 156
SELF3000 PAG. 162
• FILTER:
WATER CAPTOR PAG. 170
Dimensions expressed in millimeters
TECHNICAL DATA
FLOW RATE VOLTAGE METER NOZZLE INLET HOSE
CODE DESCRIPTION FLUIDS L/MIN GPM AC V./HZ POWER MAX. TYPE TYPE FILTER BSP LENGTH BSP
TYPE
Ø
AMP.
MM
DC VOLT
WATT
WITHOUT METER
F00372000 DRUM EX50 12V DC ATEX + MAN. NOZZLE D G K 50 13 12 250 21 - SELF3000 YES 1” 4 3/4”
F00372010 DRUM EX50 12V DC ATEX + AUT. NOZZLE D G K 50 13 12 250 21 - A60 YES 1” 4 3/4”
F00372020 KIT DRUM EX50 12V DC ATEX D G K 50 13 12 250 21 - NO NO 1” - -
F00372030 DRUM EX50 12V DC ATEX + MAN. NOZZLE + CABLE D G K 50 13 12 250 21 - SELF3000 YES 1” 4 3/4”
F00372040 DRUM EX50 12V DC ATEX + AUT. NOZZLE + CABLE D G K 50 13 12 250 21 - A60 YES 1” 4 3/4”
F0037400A DRUM EX50 230V ATEX + MAN. NOZZLE D G K 50 13 230/50-60 250 1 - SELF3000 YES 1” 4 3/4”
F0037401A DRUM EX50 230V ATEX + AUT. NOZZLE D G K 50 13 230/50-60 250 1 - A60 YES 1” 4 3/4”
F0037402A KIT DRUM EX50 230V ATEX D G K 50 13 230/50-60 250 1 - NO NO 1” - -
WITH METER
F0037500A DRUM EX50 12V DC K33 ATEX + MAN. NOZZLE D G K 50 13 12 250 21 K33 SELF3000 YES 1” 4 3/4”
F0037501A DRUM EX50 12V DC K33 ATEX + AUT. NOZZLE D G K 50 13 12 250 21 K33 A60 YES 1” 4 3/4”
F0037502A DRUM EX50 12V DC K33 ATEX + MAN. NOZZLE + CABLE D G K 50 13 12 250 21 K33 SELF3000 YES 1” 4 3/4”
F0037503A DRUM EX50 12V DC K33 ATEX + AUT. NOZZLE + CABLE D G K 50 13 12 250 21 K33 A60 YES 1” 4 3/4”
F0037600B DRUM EX50 230V K33 ATEX + MAN. NOZZLE D G K 50 13 230/50-60 250 1 K33 SELF3000 YES 1” 4 3/4”
F0037601B DRUM EX50 230V K33 ATEX + AUT. NOZZLE D G K 50 13 230/50-60 250 1 K33 A60 YES 1” 4 3/4”
( ) UPON REQUEST IT IS AVAILABLE WITH DIFFERENT VOLTAGES AND 60 HZ FREQUENCY. COMPATIBLE FLUIDS: DIESEL, KEROSENE, PETROL,
PETROL ALCOHOL MIXED MAX 15%, AVGAS 100/100LL (ONLY PUMP&METER), JET A/A1 (ONLY PUMP&METER), ASPEN 2/4 EX50 DRUM
ATEX KITS 59
