INDEX

A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

CHART IN THE BOX

• PISTOL-ONE NOZZLE
• NEXT/2 METER
• INSTRUCTION MANUAL

DETAILS

RESET BUTTON SELECTED MATERIAL
TYPE OF FLUID OIL SAE 10W40
TEMPERATURE 23 °C
DIMENSIONS

METER WITH OVAL GEARS MULTIFUNCTIONAL DISPLAY
EASY NEXT/2 NOZZLE METER SIDE
MATERIALS
370 107
• NOZZLE BODY: ALLUMINIUM
• VALVE: NBR, NICKEL PLATED STEEL,BRASS
• METER BODY: ALLUMINIUM
140 • GEARS: TECHNOPOLYMER

RIGID / FLEXIBLE SPOUT 584

750

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW RATE WORKING BATTERY
CODE DESCRIPTION FLUIDS TYPE SPOUT TYPE SEMI AUTOMATIC PRESSURE INCLUDED INLET OUTLET
NO DRIP VALUE L/MIN GPM BAR PSI AAA NO. 2 2
X 1,5 V
F00974000 EASY NEXT/2 ¾” BSP W/O SPOUT O - - 6 - 60 1,5 - 15 70 994 2 3/4” BSP -
F00974010 EASY NEXT/2 ¾” BSP W/RIGID SPOUT O RIGID YES 6 - 60 1,5 - 15 70 994 2 3/4” BSP RIGID EXT.
F00974020 EASY NEXT/2 ¾” BSP W/FLEX SPOUT O FLEXIBLE YES 6 - 60 1,5 - 15 70 994 2 3/4” BSP FLEX EXT.
EASY NEXT/2

METERED NOZZLES 91
