375Foam equipment & accessories 13LS3 foam injector lances LS10 foam injector lancesR+M Nr.540 500 09Foam injector lancesBottles for LS3Bottles for LS10R+M Nr.540 30 3/8\540 300 8 1/4\540 300 1 M22 F540 300 M22 M540 300 3 ST-3100R+M Nr.540 35 1.5 3/8\1 l540 352 1.5 3/8\2 l540 40 1.5 M22 M 1 l540 402 1.5 M22 M 2 l540 355 1.5 plug KW 1 l540 355 2 1.5 plug KW 2 lR+M Nr.540 500 25 LS3 1 lR+M Nr.540 351 LS10 1 l540 352 1 LS10 2 lR+M Nr.540 500 1.25 1/4\1 l540 505 1.25 M22 F 1 l540 502 1.25 M22 M 1 l540 506 1.25 plug KW 1 l540 503 1.25 bayonet K brass 1 l540 504 1.25 bayonet K PVC 1 lLance with regulator 1.5. Max. 200 bar / 65 %u00b0C / 25 l/minLance with regulator and bottle. Max. 200 bar / 65 %u00b0C / 25 l/minLance with regulator and bottle. Max. 180 bar / 60 %u00b0C / 12 l/minFoam padSymbols inlet packing unit nozzle volume threadFoam gunApplicationsDesigned for applications with acidic and caustic cleaner, soaps, disinfectants, degreasing and softening agents. The field of application is very versatile.%u00bb Food industry and canteen kitchen%u00bb Sanitary facilities and swimming baths%u00bb Cleaning of trucks, cars and other vehicles%u00bb Garages and petrol stations%u00bb Shops and workshopsThe foam gun directly connected to the public water pipe produces a cleaning foam by means of foam injector. The water pressure sucks in the cleaning agent and air, both are being mixed to consistent foam, sprayed out via the spraying head and the foam wand. The cleaning agent can also purposely and automatically be diluted via a built-in proportioner so that the right mixture of chemical and water as foam can be chosen for the cleaning application.Technical specificationsWater pressure 2.5 - 6 bar (for maximum accuracy 3 - 4 bar)Output 5.5 l/minMixing RatioMulti-ratio dial has 5 mixing settings and offFeatures%u00bb Exceptional chemical resistance to acidic and caustic cleaner.%u00bb Foam generating wand creates a thick clinging foam.%u00bb Automatic dosing of chemicals.%u00bb Durable polymer mixing head with stainless steel screws.%u00bb Multi-ratio dial has 5 mixing settings and off.%u00bb Gun is removable from quick coupling for clear rinsing with water.%u00bb Easy filling by means of wide mouth.%u00bb Only works with water pipe pressure.%u00bb Suitable for all customary water couplings.%u00bb Chemical container volume 1,000 ml.Please use the backflow preventer (R+M Nr. 734 10) on page 27.A B C D E 01:128 1:64 1:32 1:20 1:10 offR+M Nr.106 996 500 incl. coupler plugs \1 l
