Nozzles & washing accessories 11

High pressure nozzles Tip cleaner
Tip nozzle
Impact = 100 %

0° 15° 25° 40° 65° High speed steel (HSS) with aluminium shaft.
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. 42 mm
02 600 02 602 40 604 90 607 40 609 052 R+M Nr.
025 602 45 604 95 609 052 200 049 042 0.5
03 600 05 602 50 605 00 607 50 609 053
034 600 06 602 55 605 05 609 34
04 600 10 602 60 605 10 607 60 609 10 Advantages of Power-MEG nozzle
045 600 20 602 70 605 20 607 70
05 600 30 602 80 605 30 607 80 609 30
055 600 40 602 90 605 40 607 90 609 305
06 600 50 603 00 605 50 608 00
065 600 60 603 10 605 60 608 10 Q Q
l/min
07 600 70 603 20 605 70 608 20 l/min
075 600 75 603 25 605 75 608 25
08 600 80 603 30 605 80 608 30 609 008
085 600 90 603 40 605 90
09 601 00 603 50 606 00 608 40 3 times saves up to
10 601 10 603 60 606 10 608 60 609 100 faster 60 % water
12 603 70 606 20 608 66
3 times higher
13 601 30 603 80 606 30 608 70
impact
15 601 40 603 90 606 40 608 80
20 601 50 606 50 609 00 609 200
Ceramic high pressure nozzles

» Ceramic inserts provide up to 10 times the life of stainless steel inserts,
maximizing your return of investment and decreasing downtime for
nozzle replacement.
» Extra long life ceramic orifice is nearly diamond-hard to resist wear.
» The used ceramic is specially designed for high pressure and elevated
1/4" M NPT temperature.
» The extremely hard ceramic insert guarantees a more precise and stron-
Impact = 100 %. Max. 300 bar / 125 °C
ger
» Wedge-shaped orifice insert seats tightly as spray pressure increases.
» The external body made out of stainless steel V2A / AISI 304 has a
polished surface which is resistant to rust and slight damages.
0° 15° 25° 40°
» The nozzles are equipped with a 1/4" M NPT connection.
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
02 610 056 613 056 620 306
025 613 076 617 656 620 356
03 613 106 617 706 621 006
035 613 206 617 806
04 613 306 617 906 621 306
045 613 406 618 006 621 406
05 613 506 618 106 621 506
055 610 606* 613 606 618 206 621 606
06 610 706* 613 706 618 306 621 706
065 610 806* 618 406 621 806
07 613 906 618 506
075 611 006* 614 006* 622 006*
08 611 106* 622 106*
09 622 306*
10 611 406* 614 406* 619 006*
11 611 506* 614 506
12 611 606* 622 606*
15 611 806* 614 806
* limited stock

279
