Page 276 - RM_2022

Lances 10

Gun extensions with handle
1/4" M. Lance with handle and insulation ST-28.2/ST-29.2 Cool & Compact. Max. 400 bar / 150 °C

R+M Nr. R+M Nr.
200 028 204 1/4" M 400 mm 430 mm zinc-plated 200 028 210 1/4" M 400 mm 1,000 mm zinc-plated
200 029 204 1/4" M 400 mm 430 mm stainless steel 200 029 210 1/4" M 400 mm 1,000 mm stainless steel

Insulations for lances

Insulations ST-9.9 Vented handles ST-9

Insulation 330 mm. Suitable for 1/4" lances. Max. 150 °C Vented handle 380 mm. Suitable for 1/4" lances. Max. 150 °C
R+M Nr. R+M Nr.
200 009 935 200 009 510

Adapter for lances
M18 M : TR20 F. K-Lock 8. Brass.
Max. 400 bar / 150° C
Insulation 330 mm. Suitable for 1/4" lances. Max. 150 °C
R+M Nr. R+M Nr.
200 009 936 K 565 686
Lance holder, two-piece

For lances with R + M / Suttner insulation and connection: For all lances with R + M / Suttner insulation. With 4 lance Lance fixation for lances
Plug nipple or male thread. fixations for mounting for connection: hand screw coupling with screw coupling or
or female thread female thread. For individual
retrofitting
R+M Nr. R+M Nr. R+M Nr.
105 610 050 105 610 055 105 610 004

Symbols outlet insulation length material

275
