Foam head ST-75
By means of the foam head ST-75 different foam applications are possible as the air injector nozzle is easily exchangeable and adaptable.
The flat spray nozzle can be infinitely adapted from the vertical position to the horizontal one. The maximum flow is dependent on the chosen
nozzle size. By means of the integrated air injector in the foam head the air is sucked in on the face side. Independent of the length of the
lance a constant foam quality is guaranteed. The spraying result is especially even as a high quality foam nozzle insert is used.
Max. 350 bar / 100 °C
Stainless steel. ST-75 with nozzle. Brass. ST-75 with nozzle. Brass. ST-75 with nozzle. Brass. ST-75 with nozzle.
Max. 350 bar / 100 °C Max. 350 bar / 100 °C Max. 350 bar / 100 °C Max. 350 bar / 100 °C
R+M Nr. * R+M Nr. * R+M Nr. * R+M Nr. *
200 075 514 1.60 1/4" F 200 075 578 1.05 1/4" F 200 075 559 1.05 1/4" F 200 075 564 1.35 1/4" F
200 075 515 1.90 1/4" F 200 075 579 1.10 1/4" F 200 075 554 1.20 1/4" F 200 075 562 1.60 1/4" F
200 075 574 1.20 1/4" F 200 075 555 1.35 1/4" F 200 075 563 1.90 1/4" F
200 075 576 1.35 1/4" F 200 075 556 1.45 1/4" F
200 075 577 1.45 1/4" F 200 075 552 1.60 1/4" F
200 075 572 1.60 1/4" F 200 075 558 1.70 1/4" F
200 075 575 1.75 1/4" F 200 075 553 1.90 1/4" F
200 075 573 1.90 1/4" F
200 075 580 2.10 1/4" F
Stainless steel. ST-75 with nozzle. Brass. ST-75 with nozzle. Brass. ST-75 with nozzle. Brass. ST-75 with nozzle.
Max. 350 bar / 100 °C Max. 350 bar / 100 °C Max. 350 bar / 100 °C Max. 350 bar / 100 °C
R+M Nr. * R+M Nr. * R+M Nr. * R+M Nr. *
200 075 512 1.60 M18 F 200 075 570 1.60 M18 F 200 075 550 1.60 M18 F 200 075 560 1.60 M18 F
200 075 513 1.90 M18 F 200 075 571 1.90 M18 F 200 075 551 1.90 M18 F 200 075 561 1.90 M18 F
Air injector nozzle Stainless steel. ST-75.1 with nozzle Brass. ST-75.1 without nozzle and Brass. ST-75.1 without nozzle and
and without foam pad. without foam pad. without foam pad.
R+M Nr. *
Max. 350 bar / 60 °C Max. 350 bar / 60 °C Max. 350 bar / 60 °C
200 075 401 1.05 03
200 075 402 1.10 035 R+M Nr. * R+M Nr. R+M Nr.
200 075 403 1.20 04 200 075 602 1.60 1/4" F 200 075 482 M 18 F 200 075 486 M18 F
200 075 405 1.35 05 200 075 603 1.90 1/4" F 200 075 493 1/4" F
200 075 425 1.40 055
200 075 406 1.45 06
200 075 409 1.50 065
200 075 427 1.55 07
200 075 407 1.60 075
200 075 408 1.70 08 Foam pad 1/4" F : M18 M. Nozzle holder EG. O-ring. 10x2. Viton
200 075 410 1.90 10 R+M Nr
200 075 413 2.10 13 540 500 09 1 R+M Nr. R+M Nr.
200 075 415 2.30 15 540 500 10 10 010 000 043 Brass 790 20 1
200 075 420 2.65 20 540 500 11 100 040 000 041 Stainless steel 790 201 00 100
* hole diameter in mm
** nozzle size in mm
