Page 337 - RM_2022

13 Foam equipment & accessories

Foam lances
ST-72 foam lances with air injector

1/4" M. Foam lance stainless steel with air injector, vented handle ST-9 380 mm, grip and stainless steel socket with nozzle. A foam injector is required.
Max. 250 bar / 80 °C
R+M Nr. * ** R+M Nr. * **
200 072 500 2.0 mm < 15 l/min green 600 mm
200 072 510 2.3 mm < 20 l/min yellow 600 mm 200 072 610 2.3 mm < 20 l/min yellow 1200 mm

200 072 520 3.2 mm > 26 l/min red 600 mm 200 072 620 3.2 mm > 26 l/min red 1200 mm
ST-72.1 foam lances with air injector

1/4" M. Foam lance stainless steel with air injector, vented handle ST-9.9 330 mm, grip and stainless steel socket with nozzle. A foam injector is required.
Max. 250 bar / 80 °C
R+M Nr. * ** R+M Nr. * **
200 072 633 2.0 mm < 15 l/min green 600 mm 200 072 634 2.0 mm < 15 l/min green 1,200 mm
200 072 625 2.3 mm < 20 l/min yellow 600 mm 200 072 626 2.3 mm < 20 l/min yellow 1,200 mm
200 072 627 2.7 mm < 26 l/min blue 600 mm
200 072 629 3.2 mm > 26 l/min red 600 mm

* air injector ** nozzle protector
Symbols length nozzle flow colour diameter packing unit material inlet

336
