06 Nipples & couplings

Elbow
Female thread : male thread

Brass Brass (short version) Brass
: R+M Nr. R+M Nr. R+M Nr.
1/8" : 1/8" 572 00 250 bar 18 mm
1/4" : 1/4" 010 005 410 350 bar 29 29 572 10 250 bar 19 mm 572 30 150 bar 26 24
3/8" : 3/8" 010 005 400 350 bar 29 29 572 20 250 bar 21 mm 572 35 150 bar 26 24
1/2" : 1/2" 572 36 150 bar 34 31

Stainless steel
: R+M Nr.
1/4" : 1/4" 579 15 150 bar 22 28
3/8" : 3/8" 579 29 150 bar 23 31
Female thread : female thread

Brass Nickel-plated brass Stainless steel
: R+M Nr. R+M Nr. R+M Nr.
1/4" : 1/4" 010 005 420 350 bar 29 mm 572 40 150 bar 26 mm 579 10 150 bar 19 mm
3/8" : 3/8" 010 005 430 350 bar 29 mm 572 50 150 bar 28 mm 575 25 150 bar 25 mm
1/2" : 1/2" 572 51 150 bar 34 mm

Brass (short version)
: R+M Nr.
1/4" : 1/4" 710 101 075 250 bar 19,5 mm
