G
CHARGING & STARTING

A | PRO START 2824 12V 24V

B | START PLUS 4824 12V 24V C | START PLUS 6824 12V 24V
B | C
TECHNICAL DATA
CODE START
AMAX
VPH
AOUT
Ah
LxWxH
V (50-60Hz) V Ah A A cm kg
230
A | PRO START 2824 829517 12 / 24 44 / 22 800 2500 20,5x33,5x36 15,2
1ph
230
B | START PLUS 4824 829570 12 / 24 40 (12V) 20 (24V) 1600 (12V) 800 (24V) 4400 (12V) 2200 (24V) 30,5 x36x63 30
1ph
230
C | START PLUS 6824 829571 12 / 24 80 (12V) 40 (24V) 2000 (12V) 1000 (24V) 6000 (12V) 3000 (24V) 30,5 x36x63 41
1ph
POWER CONVERTERS BATTERY LINK 2.0
IDEAL 12V
FOR
230V

DOWNLOAD APP CONNECT & PAIRING TRACK & TEST

D | CONVERTER 310 USB E | CONVERTER 500 F | CONVERTER 1000
BL 4.0
TECHNICAL DATA Battery Link 2.0 12V
CODE MAX
V IN
P POUT
V OUT F OUT
LxWxH
TECHNICAL DATA
V (50-60Hz) V Hz W W cm kg
230
D | CONVERTER 310 USB 829444 12 50 300 600 17 x 9,5 x 5,4 0,8 CODE
1ph
LxWxH
230
E | CONVERTER 500 829446 12 50 500 1000 23,2 x 13 x 7,1 1,9 V cm
1ph
G | BATTERY 12V
230 804133 5,5x3,5x1,5
F | CONVERTER 1000 829447 12 50 1000 2000 33,7 x 13 x 7,1 2,8 LINK 2.0 (6V - 20V / 2 mA)
1ph
C
E
T
O
T
BOOSTER CABLES ARC PROTECTORR
CAVI AVVIAMENTO • CABLES DE DEMARRAGE • CABLES DE ARRANQUE • STARTEN KABEL • CABOS BOOSTER
ELECTRONIC
CONTROL
12V
POWER LINE POWER LINE PRO LINE 802840
3 m Ø 16 mm 250A 802746 3 m Ø 16 mm 250A 802698 3 m Ø 16 mm 350A 802515 Provides surge protection (voltage peaks - welding arcs) for the on-board
3 m Ø 25 mm 350A 802747 3 m Ø 25 mm 550A 802516 electronics during maintenance interventions when connected to the
3 m Ø 35 mm 800A 802668 vehicle battery.
70
