Page 38 - Air-powered pumps 180

1" 1" Metallic Diaphragm Pump
197 l/min Pompe métallique à membranes 1"
Bomba metálica de membrana, 1"
Pompa metallica a membrana da 1"

Air consumption in liters / sec • Consommation d’air en litres / seconde
Consumo de aire en litros / segundo • Consumo d’aria in litri / sec

2 7 10 14 18 23
100 10
Total discharge head (m)
80 8Hauteur totale de charge au refoulement (m)

Altura de descarga total (m)60 6 12
Altezza di mandata totale (m)
NPSH required in meters40 48

NPSH requis en mètres20 24
NPSH necesario en metros

NPSH richiesta in metri)
00 0
0 45 90 135 180 225

Flow rate (liters / min.) • Débit (litres / minute)
Caudal (litros / minuto) • Portata (litri / min.)

PD10A-AAS-FAA Dimensions R
Dimensiones
Specifications – Especificaciones – Caratteristiche Dimensioni E
F
1:1 L

197 l/min N H 3/4-14 NPT
J 1/4-18 NPTF
0.88 litre 1 - 11 1/2 NPTF: model PX10X-A…
Rp 1-11 BSP parallel: model PX10X-B… A P
8.3 bar (120 psi) Q

bar

3.3 mm

5.70 m

PD10R-XA… 9.4 kg (aluminium) (1)
PD10R-XC… 16.0 kg (cast iron) (1)
PD10R-XH… 18.0 kg (Hastelloy) (1)
PD10R-XS… 17.3 kg (stainless steel) (1)

(1) + 2.10 kg with aluminium motor.
+ 5.0 kg with stainless steel motor.

Model PX10A… PX10R… PX10S… B K
G C
A (mm) 313 313 313
M
B 294 294 294
C 101.5 101.5 101.5 D
D
E 32 32 32 1 - 11 1/2 NPTF: model PX10X-A…
F — 280 — Rp 1-11 BSP parallel: model PX10X-B…
G 207 211 208
H 316 316 316
J 159 159 159
K 186 186 186
L 10 10 10
M 38 38 38
N 164 164 164
P 7 7
Q 148 7 148
R 305 148 305
356 305 352
—

38
