FILTRATION
FILTRATION TANK MONITORING HOSE REEL ACCESSORIES MERCHANDISE
INDEX

A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

PRODUCTS IN THE BOX
CHART
• FILTER CARTRIDGE
• METALLIC HEAD
• ADDITIONAL CARTRIDGE
• INSTRUCTION MANUAL
B
F

C
A

D DETAILS
B
F

STRAINER CARTRIDGE IMPURITIES PAPER CARTRIDGE
C
A
DIMENSIONS

D WATER PAPER CARTRIDGE DRAIN VALVE
B MATERIALS

F • FILTER: ABSORBENT FILTERING PAPER
CODE A B C D F
(MM) (MM) (MM) (MM)
F00611B00 - 171 270 - -
F00611B10 - 171 270 - - C
F00611B60 - 171 270 - - A
F00611030 110 - - 75 1” BSP M
D
F00611040 155 - - 75 1” BSP M
F00611060 110 - - 75 1” BSP M
F15744000 - 171 - - 1” BSP F

TECHNICAL DATA
FLOW RATE INLET / OUTLET EFFICIENCY MICRO PRESSURE
WATER
CODE DESCRIPTION FLUIDS TYPE ABSORBING
L/MIN GPM BSP ß µ m BAR
CLEAR CAPTOR
F00611B00 CLEAR CAPTOR FILTER B D G 100 26,4 1” NO 2 5 5
F00611B10 CLEAR CAPTOR WATER FILTER B D G 70 18,5 1” YES 200 30 5
F00611B60 CLEAR CAPTOR STRAINER B D G 100 26,4 1” NO 2 125 5
CLEAR CAPTOR CARTRIDGE
F00611030 CLEAR CAPTOR CARTRIDGE B D G 100 26,4 - NO 2 5 -
F00611040 CLEAR CAPTOR WATER FILTER CARTRIDGE B D G 70 18,5 - YES 200 30 -
F00611060 CLEAR CAPTOR STRAINER CARTRIDGE B D G 100 26,4 - NO 2 125 -
CLEAR CAPTOR FILTER HEAD
F15744000 FILTER HEAD CLEAR CAPTOR B D G - - 1” NO - - -
CLEAR CAPTOR

FILTERS 173
