CHART IN THE BOX

• PUMP
• TELESCOPIC SUCTION PIPE
• DELIVERY HOSE
• NOZZLE
• 2” CONNECTOR
• K33 MECHANICAL METER (ON REQUEST)
• INSTRUCTION MANUAL

DETAILS

2” CONNECTOR TELESCOPIC SUCTION HOSE
TYPE OF FLUID DIESEL
TEMPERATURE 10°C
DIMENSIONS

244 206 ELECTRIC CABLE WITH CLAMPS
(ONLY DC VERSION)
COMPONENTS
MATERIALS
• PUMPS:
PANTHER AC PAG. 102
BIPUMP PAG. 116
PANTHER DC PAG. 114
345 • METER: PAG. 146
K33

Dimensions expressed in millimeters

TECHNICAL DATA
CODE FLOW RATE VOLTAGE METER NOZZLE INLET HOSE
TYPE
WITHOUT WITH DESCRIPTION FLUIDS L/MIN GPM AC V./HZ POWER AMP. TYPE TYPE BSP LENGTH
METER METER DC VOLT WATT MAX.
000271P00 000272P00 DRUM PANTHER 56 D 56 15 230/50 350 3 K33 SELF2000 3/4” 4M
000273P00 000274P00 DRUM PANTHER 56 A60 D 56 15 230/50 350 3 K33 A60 3/4” 4M
F0022201A F0022205A DRUM BIPUMP 12V D 80 21 12V 530 44 K33 SELF2000 1” 4M
F0022202A F0022206A DRUM BIPUMP 24V D 80 21 24V 540 22,5 K33 SELF2000 1” 4M
F0022203A F0022207A DRUM BIPUMP 12V A120 D 80 21 12V 530 44 K33 A120 1” 4M
F0022204A F0022208A DRUM BIPUMP 24V A120 D 80 21 24V 540 22,5 K33 A120 1” 4M
- F0034111C DRUM PANTHER DC 24/12V K33 A60 D 56 15 24/12V 150 25/16A K33 A60 3/4” 4M
DRUM

DRUM 67
