INSTALLATION IN THE BOX

• AIR/WATER HOSE REEL
Different ways to install PIUSI’s hose reels: they can be easily placed wherever
you need them without any problem about functionality and safety. • WALL MOUNT BRACKET
PIUSI’s products are without a doubt designed to support your work in any • HAND PROTECTION
condition. • INSTRUCTION MANUAL

ROOF WALL GROUND
INSTALLATION INSTALLATION INSTALLATION

DETAILS

AUTOMATIC HOSE REEL 4 ROLLS HOSE GUIDE

DIMENSIONS

MODEL OPEN HOSE DIFFERENT INSTALLATIONS PROTECTION ON REQUEST
REEL SMALL D
MATERIALS
A 475 F
B 460 A H
• BODY: CAST IRON
C 102 • HUB: SYNTHERED STEEL E
G
C
D
D 150 • TUBE: RUBBER
E 196 F B
F A 150 H
G 150
C G E
H 12

B Dimensions expressed in millimeters

TECHNICAL DATA
HOSE MAX WORKING PRESSURE INLET WITH OUTLET HOSE MAX LEN- HOSE
CODE DESCRIPTION FLUIDS TYPE PRESSURE DROP SWIVEL HOSETAIL GHT BOUND LENGHT
BSP BAR BAR BSP BSP M M
WITH HOSE
HA20151200A OPEN HOSE REEL 1/2” + 15MT HOSE SMALL A W A 1/2” - 1/2” MALE 1/2” MALE - 15
HA20153800A OPEN HOSE REEL 3/8” + 15MT HOSE SMALL A W A 3/8” - 3/8” FEMALE 3/8” FEMALE - 15
AIR/WATER HOSE REEL

OPEN HOSE REEL 173
