HOSE REELS
FILTRATION FLUID TANK HOSE REELS ACCESSORIES MERCHANDISE
MONITORING MONITORING
INDEX
A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

INSTALLATION IN THE BOX

• GREASE HOSE REEL
Different ways to install PIUSI’s hose reels: they can be easily placed wherever
you need them without any problem about functionality and safety. • WALL MOUNT BRACKET
PIUSI’s products are without a doubt designed to support your work in any • INSTRUCTION MANUAL
condition.

ROOF WALL GROUND
INSTALLATION INSTALLATION INSTALLATION

DETAILS

4 ROLLS HOSE GUIDE FIX SUPPORT PLATE

DIMENSIONS

MODEL CLOSE E SWIVEL
HOSE REEL
F C MATERIALS
A 516
B 259
• BODY: CAST IRON
C 491 B • HUB: SYNTHERED STEEL
D 295 • TUBE: RUBBER
D G C A
E 123
F 90
H
G 270
H 10,5
I 160
I

Dimensions expressed in millimeters

TECHNICAL DATA
HOSE MAX
OUTLET
HOSE
SWIVEL
DROP
PRESSURE
CODE DESCRIPTION FLUIDS HOSE MAX WORKING PRESSURE INLET WITH HOSETAIL LENGHT BOUND LENGHT
TYPE
BSP BAR BAR BSP BSP M M
WITH HOSE
HC40123800A REEL CLOSED 400B W/3/8” 12MT GREASE R G 3/8” 400 50@600 GR/MIN** 3/8” MALE 3/8” MALE - 12
WITHOUT HOSE
HNC40151400 REEL CLOSED 400B W/O 1/4” MAX 15M GREASE R G 1/4” 400 - 1/4” FEMALE 1/4” FEMALE 15 -
GREASE HOSE REEL
(*) PRESSURE DROP FOR GREASE NLGI 2.5 (**) PRESSURE DROP FOR GREASE NLGI 2
CLOSED HOSE REEL 177
