FILTRATION FLUID TANK HOSE REELS ACCESSORIES MERCHANDISE
MONITORING MONITORING
INDEX

A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN

CHART IN THE BOX
PIUSI P60:1 BOOSTER • P60:1 BOOSTER PUMP
• INSTRUCTION MANUAL

DETAILS

STURDY STRUCTURE HEAVY DUTY BODY
TYPE OF FLUID OIL SAE 20 (ISO VG68)
TEMPERATURE 18 °C
DIMENSIONS
PIUSI P60:1 - 470 PIUSI P60:1 - 730 PIUSI P60:1 - 940
INDUSTRIAL DESIGN PRESSURE REGULATOR
MATERIALS
113113113 • AIR MOTOR: TECHNO POLYMER
• BODY: DIE CAST STEEL
• SEAL: NBR
A A A
B B B
A A A A A A

B B B B B B

0:1 730
PIUSI P6 0:1 4 7 0 PIUSI P60:1 730 PIUSI P60:1 940
PIUSI P60:1 470
PIUSI P6
0:1 9
PIUSI P6
4
0
MEASURE “A” 740MM MEASURE “A” 1000MM MEASURE “A” 1210MM
MEASURE “B” 470MM MEASURE “B” 730MM MEASURE “B” 940MM
Dimensions expressed in millimeters
TECHNICAL DATA
DRUM-SIZE SUCTION PIPE WORKING AIR AIR INLET GREASE SIDE POLYURETHANE
PRESSURE
CODE DESCRIPTION FLUIDS COMPRESSION CONSUMPTION CONNECTION CONNECTION SEALS
TYPE
RATIO
Ø
KG MM LENGHT BAR PSI L/MIN BSP OUTLET BSP BSP
MM
PIUSI P60:1 BOOSTER
F0021605A PIUSI P60:1 470 R G 18 30 30 470 60:1 4-7 58-116 130-160 F.1/4” M.1/4” YES
F0021606A PIUSI P60:1 730 R G 50 60 30 730 60:1 4-7 58-116 130-160 F.1/4” M.1/4” YES
F0021607A PIUSI P60:1 940 R G 180 200 30 940 60:1 4-7 58-116 130-160 F.1/4” M.1/4” YES
P60:1 BOOSTER
*MEASURING MADE WITH PUMP ASSEMBLED OVER DRUM TAKEN FROM 1 METER DISTANCE WITHOUT ANY ENVIROMENTAL NOISES.
PNEUMATIC PISTON PUMPS 31
