CHART IN THE BOX

• VISCOMAT GEAR PUMP
• ANTI-SIPHON KIT
• INSTRUCTION MANUAL

DETAILS

ON/OFF SWITCH ADJUSTABLE BYPASS
TYPE OF FLUID OIL SAE 10W40
TEMPERATURE 19 °C
DIMENSIONS

VISCOMAT GEAR 200/2
92
MATERIALS
• BODY: CAST IRON
• GEARS: SINTERED STEEL
201 • SHAFT: STEEL

VISCOMAT GEAR 230/3 • BYPASS: BRASS
VISCOMAT GEAR 350/2
112 327

225

125 350

Dimensions expressed in millimeters
TECHNICAL DATA
FLOW RATE WORKING VOLTAGE INLET
PRESSURE
CODE DESCRIPTION FLUIDS TYPE RPM OUTLET BYPASS
VALVE
L/MIN GPM BAR PSI MOTOR POWER AMP. BSP
V./ HZ
WATT
MAX.
F0030403D VISCOMAT 200/2 M. SINGLE-PHASE O 9 2,4 12 170 230/50/60 800/950 3,8/4,6 1450/1700 1” BSP YES
F0030430D VISCOMAT 230/3 M. SINGLE-PHASE O 14 3,7 16 227 230/50 1250 6 1400 1” BSP YES
F0030401D VISCOMAT 350/2 M. SINGLE-PHASE O 9 2,4 25 355 230/50 1200 6 1250 1” BSP YES
F0030405D VISCOMAT 200/2 THREE-PHASE O 9 2,4 12 170 400/50 550 1,5 1450 1” BSP YES
F00304T1D VISCOMAT 350/2 THREE-PHASE O 9 2,4 25 355 400/50 750 2,5 1450 1” BSP YES
F00304T4D VISCOMAT 230/3 THREE-PHASE O 14 3,7 12 170 400/50 1200 2,7 1400 1” BSP YES
UPON REQUEST IT IS AVAILABLE WITH DIFFERENT VOLTAGE AND FREQUENCY - (*) WITHOUT ADJUSTABLE BYPASS VALVE - (**)
MEASURING MADE WITH PUMP ASSEMBLED OVER DRUM TAKEN FROM 1 METER DISTANCE WITHOUT ANY ENVIROMENTAL NOISES. VISCOMAT GEAR
ELECTRIC PUMPS 35
